Magnetic resonance imaging needs a magnetic field strength of 1.5 T. The solenoid is 1.8 m long and 75 cm in diameter. It is tightly wound with a single layer of 2.0-mm-diameter superconducting wire. What size current is needed?

Short Answer

Expert verified

I=2.4×103A

Step by step solution

01

Part 1 : Given information

The solenoid is wounded in number of turns Nand due to the current in this wounded wire, there is a magnetic field produced in a uniform shape at the center of solenoid where equation (29.17) gives the magnetic field every where inside the infinite solenoid and along the central axis of an infinite solenoid the magnetic field is given by

B=μ0NIl

Where Nis the number of turns, Lits length, Iis the current in the solenoid and μ0is the free space permeability and equals

4π×10-7T.m/A

02

calculation

By solving for Iwe get

role="math" localid="1649234083484" I=Blμ0N

The number of turns equals the length of the solenoid by the diameter of the thin layer N=1.8m2×10-3m=900turns

Now let us plug the values for μ0,B,landNinto equation (2) to get the current in the solenoid

role="math" localid="1649234517945" I=Blμ0N=(1.5T)(1.8m)(4π×10-7T.m/A)(900turns)=2.4×103A
