Chapter 12: Q. 17 (page 330)

A 25 kg solid door is 220 cm tall, 91 cm wide. What is the door's moment of inertia for (a) rotation on its hinges and (b) rotation about a vertical axis inside the door, 15 cm from one edge?

Short Answer

Expert verified

The moment of inertia about the edge of slab is 6.9kgm2

The moment of inertia about 15 cm from the edge of slab is4.1kgm2

Step by step solution

01

Step 1. Given information

A mass of solid door m=25kg, height of door a=220cm, , and 91cm wide.

02

Part (a)

The door is a slab of uniform density.

The hinges are at the edge of the door, So moment of inertia about the edge of slab is

I=13Ma2I=1325kg0.91m2=6.9kgm2

The moment of inertia about the edge of slab is6.9kgm2

03

Part (b)

The distance from the axis through the center of mass along the height of the door is

d=0.91m2鈭�0.15m=0.305m

. Using the parallel-axis theorem,

The moment of inertia about 15 cm from the edge of slab is

I=Icm+Md2=11225kg0.91m2+25kg0.305cm2=4.1kgm2

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

During most of its lifetime, a star maintains an equilibrium size in which the inward force of gravity on each atom is balanced by an outward pressure force due to the heat of the nuclear reactions in the core. But after all the hydrogen 鈥渇uel鈥� is consumed by nuclear fusion, the pressure force drops and the star undergoes a gravitational collapse
until it becomes a neutron star. In a neutron star, the electrons and protons of the atoms are squeezed together by gravity until they fuse into neutrons. Neutron stars spin very rapidly and emit intense pulses of radio and light waves, one pulse per rotation. These 鈥減ulsing
stars鈥� were discovered in the 1960s and are called pulsars.
a. A star with the mass M = 2.0 x 1030 kg and size R =7.0 x 108 m of our sun rotates once every 30 days. After undergoing gravitational collapse, the star forms a pulsar that is observed by astronomers to emit radio pulses every 0.10 s. By treating the neutron star as a solid sphere, deduce its radius.
b. What is the speed of a point on the equator of the neutron star? Your answers will be somewhat too large because a star cannot be accurately modeled as a solid sphere. Even so, you will be able to show that a star, whose mass is 106larger than the earth鈥檚, can be compressed by gravitational forces to a size smaller than a typical state in the United States!

A satellite follows the elliptical orbit shown in FIGURE P12.77. The only force on the satellite is the gravitational attraction of the planet. The satellite鈥檚 speed at point a is 8000 m/s.
a. Does the satellite experience any torque about the center of the planet? Explain.
b. What is the satellite鈥檚 speed at point b?
c. What is the satellite鈥檚 speed at point c?

FIGURE CP12.89 shows a cube of mass m sliding without frictionat speed v0. It undergoes a perfectly elastic collision with the bottom tip of a rod of length d and mass M = 2m. The rod is pivoted about a frictionless axle through its center, and initially it hangs straight down and is at rest. What is the cube鈥檚 velocity鈥� both speed and direction鈥攁fter the collision?

A thin, uniform rod of length L and mass M is placed vertically on a horizontal table. If tilted ever so slightly, the rod will fall over.
a. What is the speed of the center of mass just as the rod hits the table if there鈥檚 so much friction that the bottom tip of the rod does not slide?
b. What is the speed of the center of mass just as the rod hits the table if the table is frictionless?

What is the angular momentum vector of the rotating bar in
