Chapter 32: Q.25 (page 925)

An inductor is connected to a $15 k H z$ oscillator. The peak current is $65 m A$ when the rms voltage is $6.0 V$ . What is the value of the inductance L?

Short Answer

Expert verified

The value of Inductance is $L = 1.38 m H$

Step by step solution

Given information

We have been given that

Frequency of oscillator is $(f) = 15 K H z$

Value of peak current $(I_{鈭�}) = 65 m A$

RMS Voltage $(V_{r m s}) = 6.0 V$

We need to find out the inductance of an inductor connected to an oscillator

Detailed solution

As we know that Inductive Reactance; $X_{L} = 2 蟺 f L$ where f is frequency of oscillator and L is inductance

$鈬� L = \frac{X_{L}}{2 蟺 f} . . . . . . (1)$

Also,

$X_{L} = \frac{V_{m a x}}{I_{m a x}} 鈬� X_{L} = \frac{\sqrt{2} V_{r m s}}{I_{m a x}} . . . . . . (2)$ where $V_{r m s} = 6 V; I_{m a x} = 65 m A$

On Putting (2) in (1) we get,

localid="1649880677194" width="356">L=2VrmsImax(2蟺f)=2脳665脳10-3脳2脳3.14脳15脳1000L=1.38mH
