Q. 44 Show that Equation聽32.27聽for t... [FREE SOLUTION]

Chapter 32: Q. 44 (page 925)

Show that Equation $32.27$ for the phase angle $蠒$ of a series $R L C$ circuit gives the correct result for a capacitor-only circuit.

Short Answer

Expert verified

The expression $蠒 = \tan^{- 1} (\frac{X_{L} - X_{C}}{R})$ for phase angle of series $R L C$ circuit gives correct result for capacitor only circuit.

Step by step solution

Given Information

We are given that the Equation $32.27$ which is $蠒 = \tan^{- 1} (\frac{X_{L} - X_{C}}{R})$ .

We need to prove that this equation for phase angle of series $R L C$ circuit gives correct result for capacitor only circuit.

Explanation

We know equation,

$\tan 蠒 = \frac{V_{L} - V_{C}}{V_{R}} 鈬� \frac{(X_{L} - X_{C})}{R I}$

Here gets canceled so equation can be rewritten as :

$蠒 = \tan^{- 1} (\frac{X_{L} - X_{C}}{R})$

We are also given that , $X_{L} = X_{C} = 0$

From here phase angle becomes $蠒 = \tan^{- 1} (0) = 0 r a d .$

Similarly for $A C$ Inductor circuit conditions are

localid="1649931138237" $R = X_{C} = 0 蠒 = \tan^{- 1} (鈭�) = 蟺 / 2 rad$

Hence proved that it gives correct result for capacitor only circuit.
