Chapter 32: Q. 39 (page 925)

A series RLC circuit with a 100惟resistor dissipates 80Wwhen attached to a 120V/60Hzpower line. What is the power factor?

Short Answer

Expert verified

The power factor of RLC circuit is0.556.

Step by step solution

01

Given Information

We are given that the resistor R=100惟, dissipating power P=80Wand the voltage V=120V.

We have to find out the power factor of the RLC circuit.

02

Formula Used

Now, using the formula,

P=V2R脳Pflet this be equation 1

where P is power, V is voltage , R is resistor and Pfis power factor.

03

Simplify

Now put the values of all variables in equation 1,

We get 80=(120)2100Pf

On rearranging,

We get, Pf=80脳100(120)2

On solving,

Pf=0.556

The power factor of RLC circuit is0.556.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

The small transformers that power many consumer products produce a12.0Vrms, 60Hzemf. Design a circuit using resistors and capacitors that uses the transformer voltage as an input and produces a 6.0Vrms output that leads the input voltage by 45掳.

A seriesRLCcircuit consists of a 25鈩�resistor, a 0.10Hinductor, and a100mFcapacitor. It draws a2.5Armscurrent when attached to a 60Hzsource. What are (a) the emfErms, (b) the phase angle蠒and (c) the average power loss?

For an RC filter circuit, show thatVR=VC=蔚02at蝇=蝇c.

A seriesRLC circuit consists of a75鈩�resistor, a 0.12H inductor, and a 30mF capacitor. It is attached to a120V/60Hz power line. What are (a) the peak currentI, (b) the phase angle 蠒, and (c) the average power loss?

A 20mHinductor is connected across an AC generator that produces a peak voltage of 10V. What is the peak current through the inductor if the emf frequency is (a)
