The ampere is the SI unit for current, and it quantifies the passage of electric charge over a surface at one coulomb per second. The unit is coulomb/Sec (C/s) or amp because the charge is evaluated in coulombs and the duration is measured in seconds.

Assumed values:

$f=10\mathrm{kHz}→1×{10}^4\mathrm{Hz}$(hertz)

$R=150\mathrm{Î\copyright }$(ohm)

$C=80×{10}^{-9}\mathrm{F}$(farad)

${\mathrm{Î\mu }}_o=10\cos wt$

localid="1650216237862" $w=2\mathrm{Ï€}f$

$=2\mathrm{π}×{10}^4\mathrm{rad}/\mathrm{s}$

The peak current is given by ,

$I=\frac{{\mathrm{Î\mu }}_0}{\sqrt{R^2+X_C^2}}$

From there, we come across

$I=\frac{{\mathrm{Î\mu }}_0}{\sqrt{R^2+X_C^2}}$

localid="1650213010427" $I=\frac{10V}{\sqrt{{150}^2\mathrm{Î\copyright }+{\left(2\mathrm{Ï€}\left({10}^4\right)×80×{10}^{-9}\right)}^{-2}F}}$

$I=0.04A$

We then calculate the captivate reactance $V_c$Where$X_C=\frac{1}{\mathrm{Ó\neg }C}=\frac{1}{2\mathrm{Ï€}fC}$

$V_C=I{X}_C$

In the equation, substitute values

localid="1650212969080" $V_C=\frac{0.04A}{2\mathrm{π}\left({10}^4\right){\left(80×{10}^{-2}\right)}^{}F}$

$V_C=8V$

The Voltage are $V_R=IR$:

$V_R=IR$

Fill in the blanks in the equation,

$V_R=0.04\mathrm{A}×150\mathrm{Î\copyright }$

$V_R=6\mathrm{V}$
