A loudspeaker on a pole is radiating 100 W of sound energy in all directions. You are walking directly toward the speaker at 0.80 m/s. When you are 20 m away, what are (a) the sound intensity level and (b) the rate (dB/s) at which the sound intensity level is increasing? Hint: Use the chain rule and the relationship log10 x = ln x/ln 10.

Short Answer

Expert verified

a) The intensity level of the sound source is 102.7 dB

b) The rate of increase in intensity level is 4.108 dB/s

Step by step solution

01

Write the given information

The power of the sound source P= 100W

The speed of the listener v = 0.80m/s

The distance of the listener from the source is d = 20m

02

(a) To determine the sound intensity level

The area covered by the sound source is 4Ï€r2

Substitute the values

Area=4(3.14)(20)2=5.24m2

The intensity of the sound is

I=PowerAreaI=100W5.24m2I=1.9×10-2W/m2

The sound intensity level is given by

β=(10dB)logIIo=10dBlog1.9×10-21×10-12=10dBlog1.9×1010=10dBlog1.9+log1010=10dB0.27+10=10dB(10.27)=102.7dB

Thus, the intensity level of the sound source is 102.7 dB

03

(b) To determine the rate of increase in sound intensity level

The time taken by the sound to reach the listener is given by

Time=distancespeedT=20m0.80m/sT=25sec

In 25 seconds, the sound reaches the listener with an intensity level of 102.7 dB

The intensity level of sound in 1 sec is given by

102.725=4.108dB/s

Thus, the rate of increase in intensity level is 4.108 dB/s

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

An avant-garde composer wants to use the Doppler effect in his new opera. As the soprano sings, he wants a large bat to fly toward her from the back of the stage. The bat will be outfitted with a microphone to pick up the singer’s voice and a loudspeaker to rebroadcast the sound toward the audience. The composer wants the sound the audience hears from the bat to be, in musical terms, one half-step higher in frequency than the note they are hearing from the singer. Two notes a half-step apart have a frequency ratio of 21/12 = 1.059. With what speed must the bat fly toward the singer?

Show that the displacement D(x,t)=cx2+dt2, where c and d are constants, is a solution to the wave equation. Then find an expression in terms of c and d for the wave speed.

An opera singer in a convertible sings a note at 600 Hz while cruising down the highway at 90 km/h. What is the frequency heard by a. A person standing beside the road in front of the car? b. A person on the ground behind the car?

A water wave is a shallow-water wave if the water depth d is less than ≈ l/10. It is shown in hydrodynamics that the speed of a shallow-water wave is v = 1gd, so waves slow down as they move into shallower water. Ocean waves, with wavelengths of typically 100 m, are shallow-water waves when the water depth is less than ≈ 10 m. Consider a beach where the depth increases linearly with distance from the shore until reaching a depth of 5.0 m at a distance of 100 m. How long does it take a wave to move the last 100 m to the shore? Assume that the waves are so small that they don’t break before reaching the shore

The sound intensity level 5.0 m from a large power saw is 100 dB. At what distance will the sound be a more tolerable 80 dB?
