Chapter 12: Q. 4 (page 330)

An 18-cm-long bicycle crank arm, with a pedal at one end, is attached to a 20-cm-diameter sprocket, the toothed disk around which the chain moves. A cyclist riding this bike increases her pedaling rate from 60rpm to 90 rpm in 10s .
a. What is the tangential acceleration of the pedal?
b. What length of chain passes over the top of the sprocket during this interval?

Short Answer

Expert verified

a. the tangential acceleration of the pedal is $5.652 脳 10^{鈭� 2} m / {sec}^{2}$

b. the length of chain passes over the top of the sprocket during this interval is $7.85 m$

Step by step solution

Part (a)

The initial and final angular velocity, 60 and 90 rpm respectively, the time period for this change of velocity, 10 seconds, and a

The radius of the crank arm, $r = 18 cm$

$\begin{array}{l} 伪 = \frac{d 蝇}{d t} = \frac{(90 鈭� 60) rpm}{10 sec} = \frac{30 rpm}{10 sec} = \frac{(\frac{30}{60 sec} 脳 \frac{rotation}{min} 脳 \frac{2 蟺 rad}{rotation})}{10 sec} \\ 伪 = 0.314 rad / s^{2} \end{array}$

Tangential acceleration

$\begin{array}{l} a_{t} = r 伪 \\ a_{t} = (18 脳 10^{鈭� 2} m) 脳 (0.314 \frac{rad}{s^{2}}) \\ a_{t} = 5.652 脳 10^{鈭� 2} m / {sec}^{2} \end{array}$

Part (b)

The initial and final angular velocity

$\begin{array}{l} 60 鈥塺辫尘 = 60 鈥塺辫尘鈰� \frac{\frac{2 蟺鈥夆赌塺补诲}{60 鈥塻}}{1 鈥夆€塺辫尘} = 6.28 \frac{rad}{s} \\ 补苍诲鈥� \\ 90 鈥塺辫尘鈥�=鈥� 90 鈥塺辫尘鈰� \frac{\frac{2 蟺鈥塺补诲}{60 鈥塻}}{1 鈥夆€塺辫尘} = 9.42 \frac{rad}{s} \end{array}$

Angle turned by the bicycle crank in

$\begin{array}{l} 胃 = 蝇_{i} t + \frac{1}{2} 伪 t^{2} \\ 胃 = (2 蟺) (10 sec) + \frac{1}{2} (0.314 rad / {sec}^{2}) {(10 sec)}^{2} \\ 胃 = 78.5 \end{array}$

If the length of chain passes over the top of sprocket

$\begin{array}{l} S = 胃 r \\ S = 78.5 脳 (0.10 m) \\ S = 7.85 m \end{array}$
