The first and second laws of thermodynamics are sometimes stated as "You can't win" and "You can't even break even." Do these sayings accurately characterize the laws of thermodynamics as applied to heat engines? Why or why not?

Short Answer

Expert verified

Yes, the efficiency of heat engine is subject to laws of thermodynamics. The first law asserts that energy is conserved and that output can never exceed input. The second law adds to this constraint by stating that output can never equalize input. As a result, the sentences are employed correctly in this context.

Step by step solution

01

Step: 1 Definition of  first law of thermodynamics:

The first law of thermodynamics, sometimes known as the law of energy conservation. The output of a heat engine can never exceed the input. It amounts to saying that " you can not win " . It symbolizes that output energy can never exceed input energy.

02

Step: 2 Definition of second law of thermodynamics:

The second law of thermodynamics explains how output energy can never become equal to input energy . Some energy is destined to be wasted in the process. In break -even case in commercial transaction , total cost and benefit become equal . Beyond this point , profit starts pouring in . Similarly in heat engine , even break even point is not achieved . That means output energy can not even become equal to input energy . This amounts to saying that even break-even point is not achieved.

03

Step: 3 Law simplification :

First law simply states that energy is conserved and output can never be greater than the input. Second law adds to this constraint that output can never be even equal to input. Hence in this sense, the phrases are correctly used.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

FIGURE P21.57shows the cycle for a heat engine that uses a gas having =1.25.The initial temperature isT1=300K, and this engine operates at20cycles per second.

a. What is the power output of the engine?

b. What is the engine's thermal efficiency?

A heat engine running backward is called a refrigerator if its purpose is to extract heat from a cold reservoir. The same engine running backward is called a heat pump if its purpose is to exhaust warm air into the hot reservoir. Heat pumps are widely used for home heating. You can think of a heat pump as a refrigerator that is cooling the already cold outdoors and, with its exhaust heat QH, warming the indoors. Perhaps this seems a little silly, but consider the following. Electricity can be directly used to heat a home by passing an electric current through a heating coil. This is a direct, 100%conversion of work to heat. That is, 15kWof electric power (generated by doing work at the rate of 15kJ/sat the power plant) produces heat energy inside the home at a rate of 15kJ/s. Suppose that the neighbor鈥檚 home has a heat pump with a coefficient of performance of 5.0, a realistic value. Note that 鈥渨hat you get鈥 with a heat pump is heat delivered, QH, so a heat pump鈥檚 coefficient of performance is defined asK=QH/Win.

a. How much electric power inkWdoes the heat pump use to deliver 15kJ/sof heat energy to the house?

b. An average price for electricity is about 40MJper dollar. A furnace or heat pump will run typically 250 hours per month during the winter. What does one month鈥檚 heating cost in the home with a 15kW electric heater and in the home of the neighbor who uses a heat pump?

A nuclear power plant generates 3000MWof heat energy from nuclear reactions in the reactor鈥檚 core. This energy is used to boil water and produce high-pressure steam at 300C. The steam spins a turbine, which produces 1000MWof electric power, then the steam is condensed and the water is cooled to 25Cbefore starting the cycle again.

a. What is the maximum possible thermal efficiency of the power plant?

b. What is the plant鈥檚 actual efficiency?

c. Cooling water from a river flows through the condenser (the low-temperature heat exchanger) at the rate of 1.2*108L/h ( 30 million gallons per hour). If the river water enters the condenser at 18C, what is its exit temperature?

A uniform rod of length L oscillates as a pendulum about a ALC pivot that is a distance x from the center.

a. For what value of x, in terms of L, is the oscillation period a minimum?

b. What is the minimum oscillation period of a 15kg,1.0-m-long steel bar?

A refrigerator using helium gas operates on the reversed cycle shown in FIGURE. What are the refrigerator鈥檚 (a) coefficient of performance and (b) power input if it operates at 60cycles per second?
