Chapter 30: Q. 70 (page 874)

70. II The current through inductance $L$ is given by $I = I_{0} e^{鈭� t / 蟿}$ .
CALC a. Find an expression for the potential difference $螖 V_{L}$ across the inductor.
b. Evaluate $螖 V_{L}$ at $t = 0, 1.0$ , and $3.0 ms$ if $L = 20 mH, I_{0} = 50 mA$ , and $蟿 = 1.0 ms$ .

Short Answer

Expert verified

Part (a) The potential difference is $螖 V_{L} = \frac{L I_{0}}{蟿} e^{鈭� \frac{t}{t}}$

Part (b) Potential difference at different times

time (S)	potential difference
0 s	1000 mV
1 s	370 mV
2 s	140 mV
3 s	50 mV

Step by step solution

Part (a)

The expression for current is,

$I = I_{0} e^{\frac{t}{r}}$

The expression for the potential difference, $螖 V_{L}$ is

$\begin{array}{l} 螖 V_{L} = 鈭� L \frac{d I}{d t} \\ 螖 V_{L} = 鈭� L \frac{d}{d t} (I_{0} e^{\frac{t}{t}}) \\ 螖 V_{L} = \frac{L I_{0}}{蟿} e^{鈭� \frac{t}{t}} 鈥� 鈥� (1) \end{array}$

The potential difference is $\frac{L I_{0}}{蟿} e^{鈭� \frac{t}{t}}$

Part (b)

$L = 20 mH$ , $蟿 = 1.0 ms$ and $I_{0} = 50 mA$

At, $t = 0 鈥娾赌� s$

$\begin{array}{l} 螖 V_{L 1} = \frac{(20 mH) (50 mA)}{(1.0 ms)} e^{鈭� 0} \\ = 1000 mV \end{array}$

At, $t = 1 鈥娾赌� s$

$螖 V_{L 2} = \frac{(20 mH) (50 mA)}{(1.0 ms)} e^{鈭� 1} = 370 mV$

At, $t = 2 鈥娾赌� s$

$螖 V_{L 3} (t = 2 s) = \frac{(20 mH) (50 mA)}{(1.0 ms)} e^{鈭� 2} = 140 mV$

At, $t = 3 鈥娾赌� s$

$螖 V_{L} = \frac{(20 mH) (50 mA)}{(1.0 ms)} e^{鈭� 3} = 50 mV$
