Q. 33 The switch in FIGURE EX30.33 has... [FREE SOLUTION]

Chapter 30: Q. 33 (page 871)

The switch in FIGURE EX30.33 has been in position 1 for a long time. It is changed to position 2 at t = 0 s. a. What is the maximum current through the inductor? b. What is the first time at which the current is maximum?

Short Answer

Expert verified

The maximum current through inductor is $0.24 脳 10^{- 4}$ A and at $4.96 脳 10^{- 4}$ s current was maximum for first time.

Step by step solution

Given information

We have given that, the switch in FIGURE EX30.33 has been in position 1 for a long time. It is changed to position 2 at t = 0 s.

Part (a) Step 1.

The formula to calculate the maximum current :

$\frac{1}{2} C V^{2} = \frac{1}{2} L I^{2}$

$I = \sqrt{\frac{C V^{2}}{L}}$

Here, I = Current

C = Capacitance

V = Potential difference

L = Inductance

Step 2.

Substituting the values in the formula :

$I = \sqrt{\frac{(2 脳 10^{- 6} F) 脳 {(12 V)}^{2}}{50 脳 10^{- 3} H}}$

$I = 0.24 脳 10^{- 4}$ A

Part (b) Step 1.

We know that $T = \frac{2 蟺}{蝇}$ ,and $蝇^{2} = \frac{1}{L C}$

So, the first time at which the current is maximum :

$t = \frac{T}{4}$

$t = \frac{2 脳蟺脳 \sqrt{L C}}{4}$

Here, t = Time at which current was maximum for the first time

L = Inductance

C = Capacitance

Step 2.

Substituting the values in the formula of t :

$t = \frac{2 脳 3.14 脳 \sqrt{(50 脳 10^{- 3} H) 脳 (2 脳 10^{- 6} F)}}{4}$

$t = 4.96 脳 10^{- 4}$ s
