Chapter 33: Q.9 (page 955)

A 4.0-cm-wide diffraction grating has 2000 slits. It is illuminated by light of wavelength $550 nm$ . What are the angles (in degrees) of the first two diffraction orders?

Short Answer

Expert verified

The angle in degree of the first two diffraction order is ${1.6}^{鈭�} and {3.2}^{鈭�}$

Step by step solution

Find angle(part a)

We know that the formula for a diffraction grating connecting the m-t h diffraction angle, the order m of the diffraction, the wavelength, and the space between two consecutive gratings is

$d \sin 鈦� 胃_{m} = m 位$

As a result, the angle at which m-t h order diffraction is observed is

$胃 = \sin^{鈭� 1} 鈦� (\frac{m 位}{d})$

Find angle(part b)

Knowing that there are 2000 gratings in $4 cm$ , the grating constant will be $500 l / cm$ . This means that the separation d is $d = \frac{1 cm}{500} = 2 路 10^{- 5} m$ .

In our case, $\frac{位}{d} = \frac{5.5 路 10^{- 7}}{2 路 10^{- 5}} = 0.0275 < < 1$ , which means we can apply the angle approximation to find the angle as $胃_{m} = \frac{m 位}{d}$ . We will then, for our angles, have $胃_{1} = 0.025 rad = 0.0275 鈰� \frac{360^{鈭�}}{2 蟺} = {1.6}^{鈭�}$

$胃_{1} = 0.025 rad = 0.0275 鈰� \frac{360^{鈭�}}{2 蟺} = {1.6}^{鈭�}$

$胃_{2} = 0.055 rad = 0.055 鈰� \frac{360^{鈭�}}{2 蟺} = {3.2}^{鈭�}$
