  1. Telephone signals are often transmitted over long distances by microwaves. What is the frequency of microwave radiation with a wavelength of 3.0 cm?
  2. Microwave signals are beamed between two mountaintops 50 km apart. How long does it take a signal to travel from one mountaintop to the other?

Short Answer

Expert verified

Part (a) The frequency of microwave radiation with a wavelength of 3.0 cm is 1010Hz.

Part (b) It takes 1.67×10-4sfor the signal to travel from one mountaintop to the other

Step by step solution

01

Part (a) Step 1. Given information:

The wavelength of the microwave is λ=3cm=0.03m

Speed of microwave signal is c=3×108m/s

The distance between two mountaintops isrole="math" localid="1650003038058" d=50km=50×103m

02

Part (a) Step 1. Calculating the frequency of the microwave radiation:

The frequency is defined as the number of complete waves passing in unit time.

The formula to calculate the frequency in a periodic wave is given by

f=cλ

Substitute 0.03 m for λand 3×108m/sfor c into the above formula to calculate the frequency.

f=3×108m/s0.03m=1010Hz

03

Part (b) Step 1. Calculating the time taken to travel the signal from one mountain top to another mountain top:

The speed is defined as the rate of change of distance with respect to time.

The formula to calculate the time taken by the signal to travel from one mountaintop to another mountaintop is given by

t=dc

Substitute 50×103mfor d and 3×108m/sfor c into the above formula to calculate the time.

t=50×103m3×108m/s=1.67×10-4s
