Chapter 12: Q. 14 (page 330)

14. II The four masses shown in FIGURE EX12.13 are connected by massless, rigid rods.
a. Find the coordinates of the center of mass.
b. Find the moment of inertia about a diagonal axis that passes through masses B and D.

Short Answer

Expert verified

a. The center of mass (x,y) is ( 0.0625, 0.050 )m

b. The moment of inertia about a diagonal is $0.00163 kg m^{2}$

Step by step solution

Part (a)

The center of mass x-component

$\begin{array}{l} x_{cm} = \frac{鈭� m_{i} x_{i}}{鈭� m_{i}} = \frac{m_{A} x_{A} + m_{B} x_{B} + m_{C} x_{C} + m_{D} x_{D}}{m_{A} + m_{B} + m_{C} + m_{D}} \\ x_{cm} = \frac{(100 g) (0 m) + (200 g) (0 m) + (300 g) (0.10 m) + (200 g) (0.10 m)}{100 g + 200 g + 300 g + 200 g} \\ x_{cm} = 0.0625 m \end{array}$

The center of mass y-component

$\begin{array}{l} y_{cm} = \frac{鈭� m_{i} y_{i}}{鈭� m_{i}} = \frac{m_{A} y_{A} + m_{B} y_{B} + m_{C} y_{C} + m_{D} y_{D}}{m_{A} + m_{B} + m_{C} + m_{D}} \\ y_{cm} = \frac{(100 g) (0 m) + (200 g) (0.08 m) + (300 g) (0.08 cm) + (200 g) (0 m)}{100 g + 200 g + 300 g + 200 g} \\ y_{cm} = 0.05 m \end{array}$

Part (b)

The length of the diagonal is,

$d = \sqrt{{(10 cm)}^{2} + {(8 cm)}^{2}} = 12.8 cm$

The distance at point and point is

$\begin{array}{l} r = \frac{d}{2} \\ r = \frac{12.8 cm}{2} = 6.4 cm \\ r_{A} = r_{C} = 6.4 cm \end{array}$

As the axis is passing through the and , so, the distance at point and is zero.

$r_{B} = r_{D} = 0$

The moment of inertia about a diagonal that passes through B and D is

$\begin{array}{l} I_{BD} = m_{A} r_{A}^{2} + m_{C} r_{C}^{2} 鈥� + 鈥� m_{B} r_{B}^{2} + m_{D} r_{D}^{2} \\ I_{BD} = (0.100 kg) {(0.064 鈥尘)}^{2} + (0.300 kg) {(0.064 鈥尘)}^{2} + 0 + 0 \\ I_{BD} = 0.00163 kg m^{2} \end{array}$
