Chapter 26: Q. 74 (page 741)

A vacuum-insulated parallel-plate capacitor with plate separation $d$ has capacitance $C_{0}$ . What is the capacitance if an insulator with dielectric constant $魏$ and thickness $d / 2$ is slipped between the electrodes without changing the plate separation?

Short Answer

Expert verified

If an insulator with dielectric constant $魏$ and thickness $d / 2$ is slipped between the electrodes without changing the plate separation then the capacitance is $C_{s} = \frac{2 魏 C_{0}}{魏 + 1}$

Step by step solution

Given Information

Parallel-plate capacitor with plate separation $= d$

Capacitance $= C_{0}$

Dielectric constant $= k$

Thickness $= d / 2$

Explanation

If we insert an insulator into such a capacitor with separation $d$ and $k = 1$ , then we can treat it as two capacitors connected in series, each with thickness $d / 2$ and $魏 = 1$

It is clear that the capacitance of the air half will be

$C_{1} = 2 C_{0}$

Since the capacitance is given as

$C = 蔚_{0} 魏 \frac{A}{d} .$

The capacitance of the other half will then clearly be

$C_{2} = 2 魏 C_{0} .$

Resulting capacitance of the considered system will be

$C_{s} = {(\frac{1}{2 C_{0}} + \frac{1}{2 魏 C_{0}})}^{- 1} = {(\frac{魏 + 1}{2 魏 C_{0}})}^{- 1}$

The resulting capacitance will be

role="math" localid="1648714430037" $C_{s} = (\frac{2 魏 C_{0}}{魏 + 1})$

Final Answer

Hence, the capacitance is $C_{s} = \frac{2 魏 C_{0}}{魏 + 1} .$
