An ideal refrigerator utilizes a Carnot cycle operating between 0°Cand 25°C. To turn 10Kgof liquid water at 0°Cinto 10Kgof ice at 0°C,

aHow much heat is exhausted into the room and

bHow much energy must be supplied to the refrigerator?

Short Answer

Expert verified

a. Heat exhausted into the room is 3645.8kJ.

b. Energy supplied to the refrigerator is305.8kJ.

Step by step solution

01

Step : 1 Given Information

Lower temperatureTo=0°C=273K

Higher temperature TK=25°C=298K

Mass of liquid water, m=10Kg.

02

Step : 2 Calculation of A

Formula used :

The coefficient of performance of refrigerator is calculated as COPCarnotref=ToTK-To=HeatremovedHeatexhausted-Heatremoved

Here,

Tois the lower temperature

TKis the higher temperature

Calculation :

Heat required to remove from the water to convert it into ice is calculated asQremoved=mLice

Here,

Lice=334kJ/kgis latent heat of fusion

Plugging the values in the above equation Qremoved=10×334=3340kJ

Now the heat exhausted into the room is calculated as ToTk-To=Heatremovedheatexhausted-Heatremoved

Plugging the values in the above equation273298-273=3340Qexhaust-3340Qexhaust=3645.8kJ

Conclusion :

Heat exhausted into the room is3645.8kJ.

03

Step : 3 Calculation of B

Formula used :

Energy supplied to the refrigerator is calculated as QSupplied=Qexhaust-Qremove

Calculation :

Energy supplied to the refrigerator is calculated as QSupplied=Qexhaust-Qremove

Plugging the values in the above equation QSupplied=3645.8-3340=3.5.8kJ

Conclusion :

Energy supplied to the refrigerator is305.8kJ.
