Question: A circuit is constructed from two batteries and two wires, as shown in Figure 18.104. Each battery has an emf of . Each wire islong and has a diameter of . The wires are made of a metal that hasmobile electrons per cubic meter; the electron mobility is . A steady current runs through the circuit. The locations marked by and labeled by a letter are in the interior of the wire. (a) Which of these statements about the electric field in the interior of the wires, at the locations marked by , are true? List all that apply. (1) The magnitude of the electric field at location G is larger than the magnitude of the electric field at location F. (2) At every marked location the magnitude of the electric field is the same. (3) At location B the electric field points to the left. (b) Write a correct energy conservation (round-trip potential difference) equation for this circuit, along a round-trip path starting at the negative end of battery 1 and traveling counterclockwise through the circuit (that is, traveling to the left through the battery, and continuing on around the circuit in the same direction). (c) What is the magnitude of the electric field at location B? (d) How many electrons per second enter the positive end of battery 2? (e)If the cross-sectional area of both wires were increased by a factor of 2, what would be the magnitude of the electric field at location B? (f) Which of the diagrams in Figure 18.105 best shows the approximate distribution of excess charge on the surface of the circuit?
