Chapter 4: Q. 4.18 (page 133)

Derive equation $4.10$ for the efficiency of the Otto cycle.

Short Answer

Expert verified

The efficiency of the Otto cycle is $畏 = 1 鈭� {(\frac{V_{2}}{V_{1}})}^{纬鈭� 1}$

Step by step solution

Introduction

Efficiency $(畏) = \frac{Net work done (W_{net})}{Heat supplied (Q_{1})}$

Heat supplied:

$Q_{1} = m C_{v} (T_{3} - T_{2}) - - - (1)$

Hear rejected:

$\begin{aligned} Q_{2} = m C_{v} (T_{4} 鈭� T_{1}) 鈭� 鈭� 鈭� (2) \\ 畏 = \frac{Q_{1} 鈭� Q_{2}}{Q_{1}} = 1 鈭� \frac{Q_{2}}{Q_{1}} 鈭� 鈭� (3) \\ From (1) and (2) \\ 畏 = 1 鈭� \frac{m C_{v} (T_{4} 鈭� T_{1})}{m C_{4} (T_{3} 鈭� T_{2})} \\ 畏 = 1 鈭� \frac{(T_{4} 鈭� T_{1})}{(T_{3} 鈭� T_{2})} 鈭� 鈭� (4) \end{aligned}$

Calculation

As it is an adiabatic process:

$\begin{aligned} T_{2} V_{2}^{纬鈭� 1} = T_{1} V_{1}^{纬鈭� 1} \\ \frac{T_{2}}{T_{1}} = {(\frac{V_{1}}{V_{2}})}^{纬鈭� 1} \end{aligned}$

Similarly,

$\begin{aligned} T_{2} V_{2}^{纬鈭� 1} = T_{1} V_{1}^{纬鈭� 1} \\ \frac{T_{3}}{T_{4}} = {(\frac{V_{4}}{V_{3}})}^{纬鈭� 1} = {(\frac{V_{1}}{V_{2}})}^{纬鈭� 1} \\ 鈭� \frac{T_{2}}{T_{1}} = \frac{T_{3}}{T_{4}} \end{aligned}$

$\frac{T_{3}}{T_{2}} = \frac{T_{4}}{T_{1}} 鈭� 鈭� 鈭� 鈭� (5)$

Subtract the above equation by 1 both sides:

$\begin{aligned} \frac{T_{3}}{T_{2}} 鈭� 1 = \frac{T_{4}}{T_{1}} 鈭� 1 \\ \frac{T_{3} 鈭� T_{2}}{T_{2}} = \frac{T_{4} 鈭� T_{1}}{T_{1}} \\ \frac{T_{1}}{T_{2}} = \frac{T_{4} 鈭� T_{1}}{T_{3} 鈭� T_{2}} = {(\frac{V_{2}}{V_{1}})}^{纬鈭� 1} \end{aligned}$

Substitute the above equation in (4):

$畏 = 1 - {(\frac{V_{2}}{V_{1}})}^{纬 - 1}$

Conclusion

Efficiency of the Otto cycle is $畏 = 1 - {(\frac{V_{2}}{V_{1}})}^{纬 - 1}$ .
