The critical flicker frequency \(\left( {cff} \right)\) is the highest frequency at which a person can detect the flicker in a flickering light source. At frequencies above the cff, the light source appear to be continuous even though it is actually flickering. An investigation carried out to see whether true average cff depends on iris color yielded the following data (based on the article 鈥淭he Effects of Iris Color on Critical Flicker Frequency鈥.

Iris color

1.Brown

2.Green

3.Blue

\({\bf{26}}.{\bf{8}}\)

\({\bf{26}}.{\bf{4}}\)

\({\bf{25}}.{\bf{7}}\)

\({\bf{27}}.{\bf{9}}\)

\({\bf{24}}.{\bf{2}}\)

\({\bf{27}}.{\bf{2}}\)

\({\bf{23}}.{\bf{7}}\)

\({\bf{28}}.{\bf{0}}\)

\({\bf{29}}.{\bf{9}}\)

\({\bf{25}}.{\bf{0}}\)

\({\bf{26}}.{\bf{9}}\)

\({\bf{28}}.{\bf{5}}\)

\({\bf{26}}.{\bf{3}}\)

\({\bf{29}}.{\bf{1}}\)

\({\bf{29}}.{\bf{4}}\)

\({\bf{24}}.{\bf{8}}\)

\({\bf{28}}.{\bf{3}}\)

\({\bf{25}}.{\bf{7}}\)

\({\bf{24}}.{\bf{5}}\)

\({J_i}\)

\({\bf{8}}\)

\({\bf{5}}\)

\({\bf{6}}\)

\({x_i}\)

\({\bf{204}}.{\bf{7}}\)

\({\bf{134}}.{\bf{6}}\)

\({\bf{169}}.{\bf{0}}\)

\({\overline x _i}\)

\({\bf{25}}.{\bf{59}}\)

\({\bf{26}}.{\bf{92}}\)

\({\bf{28}}.{\bf{17}}\)

\(n = 19,{x_{..}} = 508.3\)

  1. State and test the relevant hypotheses at significance level\(.05\)(Hint:\(\sum {\sum {{x_{ij}}^2} = 13659.67,CF = 13598.36} \))
  2. Investigate difference between iris colors with respect to mean cff.

Short Answer

Expert verified

For the part \(\left( a \right)\), we need to reject the null hypotheses. And for the problem part \(\left( b \right)\)gives that there is only statistical difference between the brown and blue color.

Step by step solution

01

Deriving the formula for Hypotheses

The hypothesis of interest are\({H_0}:{\mu _i} = {\mu _j},i \ne j\)versus alternative hypothesis\({H_a}:At{\rm{ }}least{\rm{ }}two{\rm{ }}of{\rm{ }}the\,\,\,\mu \_i's\)are different, where\({\mu _i}\)is the true average of CFF for\(3\)colours,\(i = 1,2,3\)

Let\({J_i},i = 1,2,...,l\)be the sample sizes of\(I\)treatments, and let\(n = \int\limits_{i = 1}^l {{J_i}} \)be the total number of observations.

Let us denote with

\(\begin{aligned}{l}{x_i} = \int\limits_{j = 1}^{{J_i}} {{x_{ij}}} \\{x_{..}} = \int\limits_{i = 1}^I {\int\limits_{j = 1}^{{J_i}} {{x_{ij}}} } \end{aligned}\)

02

Formula for SST,SSTr,SSE and the Degrees of Freedom

The total sum of squares\(\left( {SST} \right)\), the treatment sum of squares\(\left( {SSTr} \right)\), the error sum of squares\(\left( {SSE} \right)\)are given by,

\(\begin{aligned}{l}SST = {\int\limits_{i = 1}^I {\int\limits_{j = 1}^{{J_i}} {\left( {{x_{ij}} - \overline x ..} \right)} } ^2} = \int\limits_{i = 1}^I {\int\limits_{j = 1}^{{J_i}} \begin{aligned}{l}{x_{ij}}^2 - \frac{1}{n}{x_{..}}^2;\\\end{aligned} } \\SSTr = \int\limits_{i = 1}^I {\int\limits_{j = 1}^{{J_i}} {{{\left( {{{\overline x }_i} - {{\overline x }_{..}}} \right)}^2} = \frac{1}{{{J_i}}} \times \int\limits_{i = 1}^I {{x^2}_i - \frac{1}{n}{x_{..}}^2;} } } \\SSE = \int\limits_{i = 1}^I {\int\limits_{j = 1}^{{J_i}} {{{\left( {{x_{ij}} - {{\overline x }_{i.}}} \right)}^2}} } = \int\limits_{i = 1}^I {\left( {{J_i} - 1} \right){s_i}^2} \end{aligned}\)

With degrees of freedom, respectively,

\(\begin{aligned}{l}df = n - 1;\\df = I - 1;\\df = \int\limits_{i = 1}^I {\left( {{J_i} - 1} \right) = n - I;} \end{aligned}\)

03

Calculating the mean square and the Treatment sum of square

Fundamental Identity : \(SST = SSTr + SSE\)

The mean square are,

\(\begin{aligned}{l}MSTr = \frac{1}{{I - 1}} \times SSTr;\\MSE = \frac{1}{{n - I}} \times SSE\end{aligned}\)

\(F\)is the ratio of the two mean square,

\(F = \frac{{MSTr}}{{MSE}}\)

The P-value is the area under \({F_{I - 1,n - I}}\) curve to the right of f.

The degrees of freedom for \(n = 133\), are,

\(\begin{aligned}{l}df = n - 1 = 19 - 1 = 18;\\df = I - 1 = 3 - 1 = 2;\\df = \int\limits_{i = 1}^I {\left( {{J_i} - 1} \right) = n - I = 19 - 3 = 16.} \end{aligned}\)

The treatment sum of square is,

\(\begin{aligned}{l}SSTr = \int\limits_{i = 1}^I {\int\limits_{j = 1}^{{J_i}} {{{\left( {{{\overline x }_i} - {{\overline x }_{..}}} \right)}^2} = \frac{1}{{{J_i}}} \times \int\limits_{i = 1}^I {{x^2}_i - \frac{1}{n}{x_{..}}^2} } } \\ = \frac{1}{8} \times {204.7^2} + \frac{1}{5} \times {134.6^2} + \frac{1}{6} \times {169.0^2} + \frac{1}{{19}} \times {508.3^2}\\ = 12621.36 - 13598.36\\ = 23\end{aligned}\)

04

Calculating the F Statistics

The total sum of square is,

\(\begin{aligned}{l}SST = \int\limits_{i = 1}^I {\int\limits_{j = 1}^{{J_i}} {{{\left( {{x_{ij}} - {{\overline x }_{..}}} \right)}^2} = \int\limits_{i = 1}^I {\int\limits_{j = 1}^{{J_i}} {{x^2}_{ij}} } } } - \frac{1}{n}{x_{..}}^2\\ = 13659.67 - 13598.36\\ = 61.31\end{aligned}\)

Fundamental Identity :

Error sum of square is \(\begin{aligned}{l}SSE = SST - SSTr\\ = 61.31 - 23 = 38.31\end{aligned}\)

The mean square is computed as,

\(\begin{aligned}{l}MSTr = \frac{1}{{I - 1}} \times SSTr = \frac{1}{2} \times 23 = 11.5;\\MSE = \frac{1}{{n - I}} \times SSE = \frac{1}{{16}} \times 38.31 = 2.39\end{aligned}\)

The value of \(F\)statistics is,

\(f = \frac{{MSTr}}{{MSE}} = \frac{{11.5}}{{2.3}} = 4.803\)

05

Concluding on the null Hypotheses

The\(P\)value is the area to the right of \(f\)value under \(F\)curve where \(F\)has Fisher鈥檚 distribution with degree of freedom \(2and16\),

\(P = P\left( {F > f} \right) = P\left( {F > 4.803} \right) = 0.02\)which was computed using the software.

Because, \(P = 0.02 < 0.05 = \alpha \)

So reject null hypotheses at significance level.

\({F_{0.05,2,16}} = 3.63 < f = 4.803 < 6.23 = {F_{0.01,2,16}}\)

Which indicates to reject the null hypothesis at significance level. The conclusion is that there is significant difference in true average for the three treatment.

06

Analysing the difference between the iris color and the CFF

For the problem \(\left( b \right)\), denote with,

\({w_{ij}} = {Q_{\alpha ,I,n - I}} \times \sqrt {\frac{{MSE}}{2} \times \frac{1}{{{J_i}}} + \frac{1}{{{J_j}}}} \)

Then the probability that

\({\overline x _i} - {\overline x _j} - {w_{ij}} < {\mu _i} - {\mu _j} < {\overline x _i} - {\overline x _j} + {w_{ij}}\)

Is approximately \(1 - \alpha \)for every \(i = 1,2,...,I\) and every \(j = 1,2,...,I\) where \(i \ne j\)

From the table in the appendix for \(\alpha = 0.05,I = 3,n - I = 16\), the following holds,

\({Q_{0.05,3,16}} = 3.65\)

Using the modified Turkey鈥檚 method to obtain the confidence interval for each pair you can conclude difference between iris colors.

07

Concluding the statistical difference between the CFF of the colors.

Given the average \({\overline x _i}and{Q_{\alpha ,I,n - I}}\) the confidence interval can be computed using the below mentioned formula,

\(\)\({\overline x _i} - {\overline x _j} - {w_{ij}} < {\mu _i} - {\mu _j} < {\overline x _i} - {\overline x _j} + {w_{ij}}\)

Compute \({w_{ij}}\),

\(\begin{aligned}{l}{w_{12}} = {Q_{0.05,3,16}} \times \sqrt {\frac{{MSE}}{2} \times \frac{1}{8} + \frac{1}{5}} = 2.27;\\{w_{13}} = {Q_{0.05,3,16}} \times \sqrt {\frac{{MSE}}{2} \times \frac{1}{8} + \frac{1}{6}} = 2.15;\\{w_{23}} = {Q_{0.05,3,16}} \times \sqrt {\frac{{MSE}}{2} \times \frac{1}{5} + \frac{1}{6}} = 2.42\end{aligned}\)

The MSE computed in the part \(\left( a \right)\) is \(MSE = 2.39\)

Hence the intervals are,

\(\begin{aligned}{l}\left( {{{\overline x }_{1.}} - {{\overline x }_{2.}} - {w_{12}},{{\overline x }_{1.}} - {{\overline x }_{2.}} + {w_{12}}} \right) = \left( { - 3.6,0.94} \right);\\\left( {{{\overline x }_{1.}} - {{\overline x }_{3.}} - {w_{13}},{{\overline x }_{1.}} - {{\overline x }_{3.}} + {w_{13}}} \right) = \left( { - 4.73, - 0.43} \right);\\\left( {{{\overline x }_{2.}} - {{\overline x }_{3.}} - {w_{23}},{{\overline x }_{2.}} - {{\overline x }_{3.}} + {w_{23}}} \right) = \left( { - 3.67,1.17} \right);\end{aligned}\)

Since only for the interval of pair \(\left( {2,3} \right)\)does not include zero, so that you can conclude that there is only statistical difference between CFF for brown and blue color.
