You make repeated measurements of the electric fieldE→due to a distant charge, and you find it is constant in magnitude and direction. At timerole="math" localid="1656916621351" t=0your partner moves the charge. The electric field doesn’t change for a while, but at timet=45nsyou observe a sudden change. How far away was the charge originally?

Short Answer

Expert verified

Originally the charge was at a distance of 13.5 m .

Step by step solution

01

Identification of the given data

The given data can be listed below as:

  • The time at which the charge moved by the partner is,t=0
  • The time at which the change was observed is, t=45ns×10-9s1ns=45×10-9s.
02

Significance of the distance

The distance moved by an object is equal to the product of the velocity of that object and the time taken by that object.

The equation of the distance of the charge is expressed as:

d=vt …(¾±)

Here, dis the distance moved by the charge, vis the velocity of the chargethat is the speed of ,the light and tis the time taken.

03

Determination of the distance of the charge

The concept of retardation is being applied here as the change of the velocity of the electric field is equal to the distance of the speed of light.

As the change has been observed after light took about to reach charge to the distance. However, the light travels about 1 ft in every 1 ns hence the charge happens at the distance of 45 ft .

Substitute 3×108m/sfor vand45×10-9s for tin equation (i).

d=3×108m/s×45×10-9s=13.5m

Thus, the charge was at a distance of 13.5m.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

A dipole is located at the origin, and is composed of charged particles with charge +e and -e, separated by a distance 2x10-10 along the axis. (a) Calculate the magnitude of the electric field due to this dipole at location <0,2×10-8,0>m. (b) Calculate the magnitude of the electric field due to this dipole at location <2×10-8,0,0>m.

At a particular location in the room there is an electric field <1000,0,0> N/C. Where would you place a single negative point particle of charge 1μCin order to produce this electric field?

An electron in a region in which there is an electric field experiences a force of magnitude 3.7×10-16N . What is the magnitude of the electric field at the location of the electron?

Two identical permanent dipoles, each consisting of charges +qand -qseparated by a distance s, are aligned along the xaxis, a distance rfrom each other, wherer≫s(Figure 13.75). Show all of the steps in your work, and briefly explain each step. (a) Draw a diagram showing all individual forces acting on each particle, and draw heavier vectors showing the net force on each dipole. (b) Show that the magnitude of the net force exerted on one dipole by the other dipole is this:

F≈14πε06q2s2r4

Three nested hollow spheres have the same centre. The innermost sphere has the radius of 2 cmand carries a uniformly distributed charge of 6 nC(1 nC=1×10-9 C). The middle sphere has a radius of5 cm and carries a uniformly distributed charge of -4 nC. The outermost sphere has a radius of 10 cm and carries a uniformly distributed charge of 8 nC.(a) What is the magnitude of the electric field at a distance of 1 cmfrom the centre? (b)What is the magnitude of the electric field at a distance of 4 cmfrom the centre?(c) What is the magnitude of the electric field at a distance of 9 cmfrom the centre?
