A horizontal force of magnitude 35.0 Npushes a block of mass 4.00 kgacross a floor where the coefficient of kinetic friction is 0.600. (a) How much work is done by that applied force on the block-floor system when the block slides through a displacement of 3.00 macross the floor? (b) During that displacement, the thermal energy of the block increases by40.0 J. What is the increase in thermal energy of the floor? (c) What is the increase in the kinetic energy of the block?

Short Answer

Expert verified
  1. The work done by the applied force on the block-floor system W=105 J.
  2. The amount of increase in thermal energy of the floor ∆Ethfloor=30.6J.
  3. The increase in the kinetic energy of the block∆K=34.4J

Step by step solution

01

Step 1: Given Data

The mass of block is m = 4.00 kg

The magnitude of horizontal force is F = 35.0 N

The coefficient of kinetic friction isμk=0.600

The displacement of the block across the floor is d = 3.00 m

The increase in thermal energy of the block is∆EthTblock=40.0J

02

Determining the concept

To solve this problem, use the equation of work done by the external force to calculate work. For the increase in thermal energy, use the equation of work due to friction force. For the increase in kinetic energy used, the equation for work relating with change in mechanical energy and change in thermal energy.

Formulae are as follow:

W=F.d∆Eth=fkdW=∆Emec+∆Eth

Where,∆Emec is change in mechanical energy, ∆Ethis change in thermal energy, d is displacement, F,fk are forces and W is work done.

03

Step 3(a): Determining the work done by the applied force on the block-floor system

Now,

W = F.d

So,

W=35.0×3.00W=105J

Hence, the work done by the applied force on the block-floor system W = 105 J.

04

Step 4(b): Determining the amount of increase in thermal energy of the floor

Now,

∆Eth=fkd

Hence, the amount of increase in thermal energy oftheblock-floor system is,

∆Eth=μkmgd=0.600×4.00×9.81×3.00∆Eth=70.6J

Now,

∆Ethfloor=∆Eth-∆Ethblock

So,

∆Ethfloor=∆Eth-∆Ethblock=70.6-40.0∆Ethfloor=30.6J

Hence, the amount of increase in thermal energy of the floor, ∆Ethfloor=30.6J.

05

Step 5(c): Determining the increase in the kinetic energy of the block

The work done on the system is equal to the sum of change in the mechanical energy and change in thermal energy of system. So,

W=∆Emec+AEth∆Emec=W-∆Eth=105-70.6∆Emec=34.4J

As the motion of the block is across the floor, there is no change in the potential energy of the block. So,

∆Emec=34.4J

Hence,the increase in the kinetic energy of the block,∆K=34.4J

Therefore, the change in kinetic energy of the block and the change in thermal energy of the floor along with the work done can be found using the corresponding equations.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

The maximum force you can exert on an object with one of your back teeth is about 750 N. Suppose that as you gradually bite on a clump of licorice, the licorice resists compression by one of your teeth by acting like a spring for which k=2.5×105N/m. Find (a) the distance the licorice is compressed by your tooth and (b) the work the tooth does on the licorice during the compression. (c) Plot the magnitude of your force versus the compression distance. (d) If there is a potential energy associated with this compression, plot it versus compression distance. In the 1990s the pelvis of a particular Triceratops dinosaur was found to have deep bite marks. The shape of the marks suggested that they were made by a Tyrannosaurus rex dinosaur. To test the idea, researchers made a replica of a T. rex tooth from bronze and aluminum and then used a hydraulic press to gradually drive the replica into cow bone to the depth seen in the Triceratops bone. A graph of the force required versus depth of penetration is given in Fig. 8-71 for one trial; the required force increased with depth because, as the nearly conical tooth penetrated the bone, more of the tooth came in contact with the bone. (e) How much work was done by the hydraulic press—and thus presumably by the T. rex—in such a penetration? (f) Is there a potential energy associated with this penetration? (The large biting force and energy expenditure attributed to the T. rex by this research suggest that the animal was a predator and not a scavenger.)
