1. Masses of the blocks,$\mathrm{m}=1.8\mathrm{kg},\mathrm{M}=10\mathrm{kg}$
2. Spring constant, $\mathrm{k}=200\mathrm{N}/\mathrm{m}$
3. The coefficient of static friction between two blocks,${\mathrm{μ}}_{\mathrm{s}}=0.40$

We write for the frictional force between two blocks from the condition for the smaller block which is on the verge of slipping. Then inserting the formulae for frictional force and angular frequency, we can find the amplitude of SHM of the spring-blocks system that puts the smaller block on the verge of slipping over the larger block.

Formula:

Newton’s second law gives the force,${\mathrm{F}}_{\mathrm{net}}=\mathrm{ma}$…â¶Ä¦â¶Ä¦(¾±)

Static frictional force,${\mathrm{F}}_{\mathrm{net}}={\mathrm{μ}}_{\mathrm{s}}\mathrm{mg}$…â¶Ä¦â¶Ä¦.(¾±¾±)

Maximum acceleration of SHM,${\mathrm{a}}_{\mathrm{m}}={\mathrm{Ó\neg }}^2{\mathrm{X}}_{\mathrm{m}}$…â¶Ä¦â¶Ä¦.(¾±¾±¾±)

Smaller block will be on the verge slipping over the larger block if the net force acting on it will be zero. For the condition of friction, the net force should be equal to that of the static frictional force. Hence, using equations (i) & (ii), we get the angular frequency as follows:

${\mathrm{μ}}_{\mathrm{S}}\mathrm{mg}={\mathrm{ma}}_{\mathrm{m}}$…â¶Ä¦â¶Ä¦..(¾±±¹)

Substitute the value of ${\mathrm{a}}_{\mathrm{m}}$

$$\begin{gathered} {\mathrm{μ}}_{\mathrm{s}}\mathrm{mg}={\mathrm{mÓ\neg }}^2{\mathrm{x}}_{\mathrm{m}} \\ \mathrm{Ó\neg }=\sqrt{\frac{\mathrm{k}}{\mathrm{m}+\mathrm{M}}}(\mathrm{Angular}\mathrm{frequency}=\mathrm{Ó\neg }) \end{gathered}$$

Hence, using the above derived& given values in equation (iii), we get the amplitude as

follows:

$$\begin{gathered} {\mathrm{x}}_{\mathrm{m}}=\frac{{\mathrm{μ}}_{\mathrm{s}}\mathrm{g}\left(\mathrm{m}+\mathrm{M}\right)}{\mathrm{k}} \\ =\frac{(0.40)\left(9.8\right)\left(1.8+10\right)}{200} \\ =0.23\mathrm{m} \\ =23\mathrm{cm} \end{gathered}$$ $\left(\mathrm{from}\mathrm{equation}(\mathrm{iv}\right),\mathrm{we}\mathrm{get}{\mathrm{a}}_{\mathrm{m}})$

Therefore, the amplitude of SHM of the spring-blocks system puts the smaller block on the verge of slipping over the larger block is 0.23m.
