1. Mass of block 1,$m_1=0.2\mathrm{kg}$
2. Speed of block 1 before collision,$v_i=8.0\mathrm{m}/\mathrm{s}$
3. Spring constant,$k=1208.5\mathrm{N}/\mathrm{m}$
4. Period of second block after collision,$T=0.140\mathrm{s}$
5. Height of fall,$h=4.90\mathrm{m}$

Using the formula for the time period, we first find the mass of the block which is attached to the spring. Next, using the formula for elastic collision, we find the velocity of the block which gets rebounded. Using the velocity and kinematic equations, we find the horizontal distance traveled.

Formula:

The time period of oscillation,

$T=2\mathrm{Ï€}\sqrt{\frac{m}{k}}$(i)

The second equation of motion,

$x-x_0=v_{i}t+\frac{1}{2}a{t}^2$…â¶Ä¦.(¾±¾±)

Law of conservation of momentum,

$v_{1f}=\left|\frac{m_1-m_2}{m_1-m_2}\right|v_{1i}$(iii)

From equation (i) and the given values, we get the mass of system as:

$$\begin{gathered} 0.140=2\mathrm{π}\sqrt{\frac{m}{1208.5}} \\ 0.{140}^2=4{\mathrm{π}}^2×\left(\frac{m}{1208.5}\right) \\ \frac{0.{140}^2×1208.5}{4{\mathrm{π}}^2}=m \\ m=0.6\mathrm{kg} \end{gathered}$$

As the collision is elastic, the rebound velocity for the block will be given as:

$$\begin{gathered} v_{1f}=\left|\frac{m_1-m_2}{m_1+m_2}\right|v_{1i} \\ =\left|\frac{0.2-0.6}{0.2+0.6}\right|×8 \\ =\left|\frac{-0.4}{0.8}\right|×8 \\ =4.0\mathrm{m}/\mathrm{s} \end{gathered}$$

Now, as the block is moving along a straight surface, the block will launch at an angle of $0^{°}$with respect to the surface.

This makes the velocity component in y- direction 0m/s and 4.0m/s in x-direction.

Here,$x-x_0=h\mathrm{and}g=9.8m/s$ and. (As the block is falling,the acceleration due to gravity will be in the direction of motion, so we take it as positive.) So, the equation (ii) can be given as:

$$\begin{gathered} h=\frac{1}{2}g{t}^2 \\ t=\sqrt{\frac{2h}{g}} \\ =\sqrt{\frac{2×4.9}{9.8}} \\ =1s \end{gathered}$$

Now using equation (ii) in x-direction$a=0$and $x-x_0=d$, we get

$$\begin{gathered} \mathrm{d}=\mathrm{v},\mathrm{t} \\ =4.0\mathrm{m}/\mathrm{s}×1\mathrm{s} \\ =4.0\mathrm{m} \end{gathered}$$

Hence, the value of horizontal distance is 4.0 m .
