Chapter 34: Q94P (page 1042)

An object is placed against the center of a spherical mirror and then moved 70 cm from it along the central axis as the image distance i is measured. Figure 34-48 gives i versus object distance p out to ps=40cm. What is the image distance when the object is 70 cm from the mirror?

Short Answer

Expert verified

The image distance is inew=-21cm.

Step by step solution

01

Step 1: Given data

  • Object distance,pgiven=70cm .
  • Horizontal Scale, ps=40cm.
02

Determining the concept

The focal length of the lens is constant for every situation. Using this concept, find the focal length from the graph. Using the value in the equation and the given object distance, find the new image distance.

Formulae are as follows:

1f=1p+1i

Here, p is the pole, f is the focal length, and i is the image distance.

03

Determining the image distance

From the graph, take one point Q having co-ordinate Q15,-10.

So,

1p+1i=1f

115+1-10=1f=1pgiven+1inew

Rearrange for the inew;

1inew=-10+15-10脳15-170=-5150-170

Solve for inew;

1inew=-1002100=-21cm

Therefore, the image distance isinew=-21cm .
