A typical light dimmer used to dim the stage lights in a theater consists of a variable inductor L (whose inductance is adjustable between zero and Lmax) connected in series with a lightbulb B, as shown in Fig. 31-34. The electrical supply is Vrms=20Vat f=60Hz; the light bulb is rated at 120 V, p=1000W. (a) What Lmax is required if the rate of energy dissipation in the lightbulb is to be varied by a factor of 5 from its upper limit of 1000W? Assume that the resistance of the lightbulb is independent of its temperature. (b) Could one use a variable resistor (adjustable between zero and Rmax ) instead of an inductor? (c) If so, what Rmax is required? (d) Why isn鈥檛 this done?

Short Answer

Expert verified

(a) The maximum value of the inductor is Lmax=7.6410-2m.

(b)Yes; one could use a variable resistor.

(c) The maximum value of the resistance is data-custom-editor="chemistry" Rmax=17.8.

(d) This is not done because the resistors would consume, rather than temporarily store, electromagnetic energy.

Step by step solution

01

Listing the given quantities:

RMS voltage,Vrms=120V

Frequency, f=60Hz

Voltage, V=120V

Power,P=1000W

02

Understanding the concepts of power and inductance =:

Define the relation between inductance, voltage, and power from the formula for power consumed by light bulb. Inserting the given values will give us the value of Lmax.Using it,Rmaxcan be found. From this, we can determinewhether inductor can be replaced by a variable resistor.

Formulas:

P=I2R2

Here, I is the current and R is the resistance.

Hence, the power is,

P=V2R

03

(a) Calculation of the Lmax  is required if the rate of energy dissipation in the lightbulb is independent of its temperature

Write the equation for power as below.

P=I2R2

From the above equation you can say that, the power the directly proportional to the square of the current. Therefore,

data-custom-editor="chemistry" PI2PminPmax=IminI2=ZminZmax2=ZminZmax

Here, Z is the impedance.

The maximum impedance is,

Zmax=R2+蝇尝max2

The minimum impedance is,

data-custom-editor="chemistry" Zmin=R

The rate of energy dissipation in the light bulb is to be varied by a factor of 5. Therefore,

5=R2+蝇尝max2R2=R2+蝇尝max2R25R2=R2+蝇尝max2Lmax2=4R22Lmax=2R

The equation of power is,

data-custom-editor="chemistry" P=V2RR=V2P

Hence, the maximuminductor is,

Lmax=2V2P=2V2P2蟺蹿=V2P蟺蹿

Substitute known numerical values in the above equation.

Lmax=120210003.1460=7.6410-2H

Hence, the maximum value of the inductor is 7.6410-2H.

04

(b) Explanation

Since,Lmax=2R

Then, one could use the variable resistor instead of an inductor.

05

(c) Calculation of the  :

As given,

Rmax+RbulbRbulb2=5

Simplifyingtheabove equation gives,

Rmax+RbulbRbulb2=5Rmax+Rbulb=5RbulbRmax=5Rbulb-RbulbRmax=5-1Rbulb=5-1V2P=5-112021000=17.8

Hence, the maximum value of resistance is data-custom-editor="chemistry" Rmax=17.8.

06

(d) Explanation:

This is not done because the resistors would consume, rather than temporarily store, electromagnetic energy.
