1. Current amplitude $I=7.50\mathrm{mA}\mathrm{or}7.50脳{10}^{-3}\mathrm{A}$,
2. Potential amplitude across capacitor $V=250\mathrm{mA}\mathrm{or}250脳{10}^{-3}\mathrm{A}$,
3. Capacitance $C=220\mathrm{nF}\mathrm{or}220脳{10}^{-9}\mathrm{F}$,

By using the relation between the potential difference across capacitors and the period, we can find the period of oscillation. After that, by using the concept of energy stored in the capacitor, we find the maximum energy stored in the capacitor. Similarly, we can find the maximum energy stored in the inductor, and from Faraday鈥檚 law, we can find the maximum rate of change of current. As the current is a function of time, we can find the maximum rate of gain of energy by the inductor.

Formulae:

Voltage drop across the capacitor, $V=I路X_C\left(\mathrm{i}\right)$

The period of oscillation, $T=\frac{2蟺}{蝇}\left(\mathrm{ii}\right)$

The capacitive reactance of the capacitor, $X_C=\frac{1}{蝇C}\left(\mathrm{iii}\right)$

Maximum energy stored in the capacitor,$U_C=\frac{1}{2}路C{V}^2\left(\mathrm{iv}\right)$

Maximum energy stored in the inductor,$U_L=\frac{L{i}^2}{2}\left(\mathrm{v}\right)$

Magnitude of emf due to the current in the inductor,$V\left(\mathrm{or}蔚\right)=L\frac{di}{dt}\left(\mathrm{vi}\right)$

The charge equation on the plate of capacitor as function of time,$q=q_{0}sin蝇t\left(\mathrm{vii}\right)$

The current equation due to the rate of charge,role="math" localid="1663136121465" $i=\frac{dq}{dt}\left(\mathrm{viii}\right)$

Substituting the reactance vale from equation (iii) in equation (i), we can get that the angular frequency of the oscillation can be given as follows:

$蝇=\frac{I}{VC}$

Now, substituting the above value in equation (ii), we can get the period of oscillation as follows:

$\begin{array}{c}T=\frac{2蟺VC}{I}\\ =\left(\frac{6.28脳250脳{10}^{-3}脳220脳{10}^{-9}}{7.50脳{10}^{-3}}\right)\\ =46.1脳{10}^{-6}\mathrm{sor}46.1\mathrm{渭蝉}\end{array}$

Hence, the value of the period is $46.1\mathrm{渭蝉}$.

Maximum energy stored in the capacitor can be calculated using equation (iv) as follows:

$\begin{array}{c}U=0.5脳220脳{10}^{-9}脳{\left(250\right)}^2脳{10}^{-6}\\ =6.88脳{10}^{-9}\mathrm{J}\end{array}$

Hence, the value of the maximum energy in the capacitor is $6.88脳{10}^{-9}\mathrm{J}$.

Maximum energy stored in inductor can be given by equation (v).

Thus, equating equations (iv) and (v), we can get the inductance value as:

$L=\frac{C{V}^2}{i^2}...............................\left(a\right)$

Thus, the value of the maximum energy using equation (v) and the above value can be given as:

$\begin{array}{c}{U}_L=\frac{C{V}^2}{2i^2}路i^2\\ =\frac{C{V}^2}{2}\\ =6.88脳{10}^{-9}\mathrm{J}\end{array}$

Hence, the value of the maximum energy stored in inductor is$6.88脳{10}^{-9}\mathrm{J}$.

From equation (vi), we get the maximum rate of change in current value as follows:

$\begin{array}{c}\frac{di}{dt}=\frac{V}{L}\\ =\left(\frac{V}{\frac{C{V}^2}{i^2}}\right)(\mathrm{from}\mathrm{equation}\left(\mathrm{a}\right))\\ =\frac{I^2}{CV}\\ =\left(\frac{{\left(7.50脳{10}^{-3}\right)}^2}{220脳{10}^{-9}脳250脳{10}^{-3}}\right)\\ =\left(\frac{56.25脳{10}^{-6}}{220脳250脳{10}^{-12}}\right)\\ =\left(\frac{56.25脳{10}^6}{220脳250}\right)\\ =1.02脳{10}^3\mathrm{A}/\mathrm{s}\end{array}$

Hence, the maximum rate of change of current is $1.02脳{10}^3\mathrm{A}/\mathrm{s}$.

The rate of charge that is current equation can be given using equation (vii) in equation (viii) as follows:

$\begin{array}{c}i=q_0蝇cos蝇t\\ =Icos蝇t(I=q_0蝇,\mathrm{maximum}\mathrm{current}\mathrm{amplitude})\\ i^2=I^{2}cos蝇t\end{array}$

Now, substituting the above value in equation (v), we get the maximum rate of energy gain by the inductor as follows:

$\begin{array}{c}\frac{d{U}_L}{dt}=\frac{L}{2}路\left(\frac{d}{dt}\left\{I^{2}cos蝇t\right\}\right)\\ =\frac{L{I}^2}{2}路蝇sin2蝇t\\ =\frac{L{I}^2}{2}路蝇\\ =0.5脳IV\\ =0.5脳7.50脳{10}^{-3}脳250脳{10}^{-3}\\ =0.938\mathrm{mW}\end{array}$

Hence, the value of the maximum rate of energy gain is $0.938\mathrm{mW}$.
