Chapter 36: Q97P (page 1115)

A spy satellite orbiting at 160 km above Earth鈥檚 surface has a lens with a focal length of 3.6 m and can resolve objects on the ground as small as 30 cm. For example, it can easily measure the size of an aircraft鈥檚 air intake port. What is the effective diameter of the lens as determined by diffraction consideration alone? Assume 位=550nm.

Short Answer

Expert verified

The effective diameter of the lens is 0.36 m.

Step by step solution

01

Describe the diffraction by a circular aperture or a lens

The expression to calculate the effective diameter of the lens is given by,

sin胃=1.22位d

Here, 位 is the wavelength, d is diameter, and 胃 is angle.

Let D be the distance between two objects, and L be the distance between Earth and satellite. Then,

L胃=D胃=DL

From the above equation,

胃=1.22位dDL=1.22位dd=1.22位LD 鈥�.(1)

02

Determine the effective diameter of the lens

Substitute 550脳10-9m for 位, 160脳103m for L, and 0.30m for D in equation (1).

d=1.22550脳10-9m160脳103m0.30m=0.36m

Therefore, the effective diameter of the lens is 0.36 m.
