Emf$蔚=12V$

Internal resistancerole="math" localid="1662562681995" $r=0.040惟$

Current i=50A

The formula for potential difference for a non-ideal battery to calculate the potential difference across the terminal of the battery. Using the power relation, find the energy dissipation inside the battery and the rate of energy conversion to the chemical form.

Formulae are as follow:

$$\begin{gathered} V=蔚-ir \\ P=i^{2}r \\ P=iV \end{gathered}$$

Where, P is power, I is current, R is resistance, 饾泦 is emf, V is voltage .

The potential difference across the terminals:

The potential difference between the terminals is given by,

$$\begin{gathered} V=蔚+ir \\ V=12V+\left(50A\right)(0.040鈩�) \\ V=14V \end{gathered}$$

Hence, the potential difference Vacross the terminals is 14V.

The rate of energy dissipation inside the battery

The rate energy dissipation is given by,

$P_r=i^{2}r=\left(50A{)}^2\right(0.040惟)=1.0脳{10}^{2}W$

Hence, the rate P_rof energy dissipation inside the battery is$1.0脳{10}^{2}W$

The rate P_emfof the energy conversion to the chemical form :

$$\begin{gathered} P=iV \\ P=50A脳12V \\ P=600W=6脳{10}^{2}W \end{gathered}$$

Hence, the rate P_emfof the energy conversion to the chemical form is$6脳{10}^{2}W$.

The current is 50A, then potential difference is as follows:

The potential difference between the terminals is given by,

$$\begin{gathered} V=蔚-ir \\ V=12V-(50A)(0.040鈩�)=10V \end{gathered}$$

Hence, the potential difference between the terminals is 10V

The current is 50A, then the rate P_rof the energy dissipation is as follows :

The rate energy dissipation is given by,

$P_r=i^{2}r=\left(50A{)}^2\right(0.040惟)=1.0脳{10}^{2}W.$

Hence, the rate energy dissipation is P_r=$1.0脳{10}^{2}W$

Therefore, use the formula for potential difference for a non-ideal battery to calculate the potential difference across the terminal of the battery and using power relation, find the energy dissipation inside the battery and the rate of energy conversion to the chemical form.
