The capacitances of two capacitors is- $5.00\mathrm{μ¹ó}$and $8.00\mathrm{μ¹ó}$ .

Capacitors in Parallel: When capacitors with capacitances C₁, C₂ ,… are connected in parallel, the equivalent capacitance C_eq equals the sum of the individual capacitances –

Capacitors in Series: When capacitors with capacitances C₁, C₂, … are connected in series, the reciprocal of the equivalent capacitance C_eq equals the sum of the reciprocals of the individual capacitances –

If the two capacitors are connected in parallel combination, their equivalent capacitance is given by Equation (1) as:

$\begin{array}{rcl}{\mathbf{C}}_{\mathbf{eq}\mathbf{,}\mathbf{p}}& \mathbf{=}& {\mathbf{C}}_{\mathbf{1}}\mathbf{+}{\mathbf{C}}_{\mathbf{2}}\\ & \mathbf{=}& \mathbf{5}\mathbf{.}\mathbf{00}\mathbf{}\mathbf{mF}\mathbf{+}\mathbf{8}\mathbf{.}\mathbf{00}\mathbf{}\mathbf{mF}\\ & \mathbf{=}& \mathbf{13}\mathbf{.}\mathbf{0}\mathbf{}\mathbf{mF}\end{array}$

If the two capacitors are connected in series combination, their equivalent capacitance is given by Equation (2) :

$\begin{array}{rcl}\frac{\mathbf{1}}{{\mathbf{C}}_{\mathbf{eq}\mathbf{,}\mathbf{s}}}& \mathbf{=}& \frac{\mathbf{1}}{{\mathbf{C}}_{\mathbf{1}}}\mathbf{+}\frac{\mathbf{1}}{{\mathbf{C}}_{\mathbf{2}}}\\ {\mathbf{C}}_{\mathbf{eq}\mathbf{,}\mathbf{s}}& \mathbf{=}& \frac{{\mathbf{C}}_{\mathbf{1}}{\mathbf{C}}_{\mathbf{2}}}{{\mathbf{C}}_{\mathbf{1}}\mathbf{+}{\mathbf{C}}_{\mathbf{2}}}\\ {\mathbf{C}}_{\mathbf{eq}\mathbf{,}\mathbf{s}}& \mathbf{=}& \frac{\mathbf{(}\mathbf{5}\mathbf{.}\mathbf{00}\mathbf{}\mathbf{μ¹ó}\mathbf{)}\mathbf{(}\mathbf{8}\mathbf{.}\mathbf{00}\mathbf{}\mathbf{μ¹ó}\mathbf{)}}{\mathbf{5}\mathbf{.}\mathbf{00}\mathbf{}\mathbf{μ¹ó}\mathbf{+}\mathbf{8}\mathbf{.}\mathbf{00}\mathbf{}\mathbf{μ¹ó}}\\ & \mathbf{=}& \mathbf{3}\mathbf{.}\mathbf{07}\mathbf{}\mathbf{μ¹ó}\end{array}$

Therefore, equivalent capacitance in the series combination and the parallel combination is $3.07\mathrm{μ¹ó}$and $13.0\mathrm{μ¹ó}$respectively.
