The propagation of fatigue cracks in various aircraft parts has been the subject of extensive study in recent years. The accompanying data consists of propagation lives(flight hours/\({\bf{1}}{{\bf{0}}^{\bf{4}}}\)) to reach a given crack size in fastener holes intended for use in military aircraft (鈥淪tatistical Crack Propagation in Fastener Holes Under Spectrum Loading,鈥 J. Aircraft,1983: 1028鈥1032):

.736 .863 .865 .913 .915 .937 .983 1.007

1.011 1.064 1.109 1.132 1.140 1.153 1.253 1.394

  1. Compute and compare the values of the sample mean and median.
  2. By how much could the largest sample observation be decreased without affecting the value of the median?

Short Answer

Expert verified
  1. The sample mean is 1.0297 flight hours/\({10^4}\).The median value is 1.009 flight hours/\({10^4}\). The mean value is greater than median.
  2. The largest sample observation can be decreased to 0.383 without affecting the median value.

Step by step solution

01

Given information

The data of propagation lives to reach a given crack size in fastener holes intended for use in military aircraft is provided.

The size of the sample is 16.

02

Compute the mean, median for the sample and compare the values

a.

Let x represents the propagation lives in flight hours/\({10^4}\)

The sample mean is computed as,

\(\begin{array}{c}\bar x &=& \frac{{\sum {{x_i}} }}{n}\\ &=& \frac{{0.736 + 0.863 + 0.865 + ... + 1.394}}{{16}}\\ &=& 1.0297\end{array}\)

Thus, the sample mean is 1.0297 flight hours /\({10^4}\).

The sample median is computed by first ordering the data in ascending order.

The data is arranged as,

0.736

0.863

0.865

0.913

0.915

0.937

0.983

1.007

1.011

1.064

1.109

1.132

1.14

1.153

1.253

1.394

For the even number of observations, the median value is computed as,

\(\begin{array}{c}\tilde x &=& {\rm{average}}\;{\rm{of}}\;{\left( {\frac{n}{2}} \right)^{th}}{\rm{and}}\;{\left( {\frac{n}{2} + 1} \right)^{th}}\;{\rm{ordered}}\;{\rm{values}}\\ &=& {\rm{average}}\;{\rm{of}}\;{\left( {\frac{{16}}{2}} \right)^{th}}{\rm{and}}\;{\left( {\frac{{16}}{2} + 1} \right)^{th}}\;{\rm{ordered}}\;{\rm{values}}\\ &=& {\rm{average}}\;{\rm{of}}\;{\left( 8 \right)^{th}}{\rm{and}}\;{\left( 9 \right)^{th}}\;{\rm{ordered}}\;{\rm{values}}\\ &=& \frac{{1.007 + 1.011}}{2}\\ &=& 1.009\end{array}\)

Thus, the median value is 1.009flight hours/\({10^4}\).

The mean value (1.0297) is greater than the median value (1.009).

03

Obtain the value by which the largest value must be decreased to keep median constant

b.

The median value is 1.009.

The largest sample observation is 1.394.

The largest sample observation should be greater than the median value so that does not affect the median value.

The value is computed as,

\(\begin{array}{c}1.394 - \tilde x &=& 1.394 - 1.011\\ &=& 0.383\end{array}\)

Thus, the largest sample value can be decreased by 0.383.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Do running times of American movies differ somehow from running times of French movies? The author investigated this question by randomly selecting 25 recent movies of each type, resulting in the following

running times:

Am: 94 90 95 93 128 95 125 91 104 116 162 102 90

110 92 113 116 90 97 103 95 120 109 91 138

Fr: 123 116 90 158 122 119 125 90 96 94 137 102

105 106 95 125 122 103 96 111 81 113 128 93 92

Construct a comparativestem-and-leaf display by listing stems in the middle of your paper and then placing the Am leaves out to the left and the Fr leaves out to the right. Then comment on interesting features of thedisplay.

Let \({{\rm{X}}_{\rm{1}}}{\rm{, \ldots ,}}{{\rm{X}}_{\rm{n}}}\) be independent \({\rm{rv's}}\) with mean values \({{\rm{\mu }}_{\rm{1}}}{\rm{, \ldots ,}}{{\rm{\mu }}_{\rm{n}}}\) and variances \({\rm{\sigma }}_{\rm{1}}^{\rm{2}}{\rm{, \ldots ,\sigma }}_{{{\rm{\sigma }}^{\rm{*}}}}^{\rm{2}}\)Consider a function\({\rm{h}}\left( {{{\rm{x}}_{\rm{1}}}{\rm{, \ldots ,}}{{\rm{x}}_{\rm{n}}}} \right)\), and use it to define a \({\rm{rv}}\)\({\rm{Y = h}}\left( {{{\rm{X}}_{\rm{1}}}{\rm{, \ldots ,}}{{\rm{X}}_{\rm{n}}}} \right)\). Under rather general conditions on the \({\rm{h}}\)function, if the \({{\rm{\sigma }}_{\rm{i}}}\)'s are all small relative to the corresponding \({{\rm{\mu }}_{\rm{i}}}\)'s, it can be shown that (\({\rm{E(Y)\gg h}}\left( {{{\rm{\mu }}_{\rm{1}}}{\rm{, \ldots ,}}{{\rm{\mu }}_{\rm{n}}}} \right)\) and\({\rm{V(Y)\hat U }}{\left( {\frac{{{\rm{露h }}}}{{{\rm{露 }}{{\rm{x}}_{\rm{1}}}}}} \right)^{\rm{2}}}{\rm{ \times \sigma }}_{\rm{1}}^{\rm{2}}{\rm{ + L + }}{\left( {\frac{{{\rm{露h }}}}{{{\rm{露 }}{{\rm{x}}_{\rm{n}}}}}} \right)^{\rm{2}}}{\rm{ \times \sigma}}_{\rm{n}}^{\rm{2}}\))where each partial derivative is evaluated at \(\left( {{{\rm{x}}_{\rm{1}}}{\rm{, \ldots ,}}{{\rm{x}}_{\rm{n}}}} \right){\rm{ = }}\)\(\left( {{{\rm{\mu }}_{\rm{1}}}{\rm{, \ldots ,}}{{\rm{\mu }}_{\rm{n}}}} \right)\). Suppose three resistors with resistances \({{\rm{X}}_{\rm{1}}}{\rm{,}}{{\rm{X}}_{\rm{2}}}{\rm{,}}{{\rm{X}}_{\rm{3}}}\)are connected in parallel across a battery with voltage\({{\rm{X}}_{\rm{4}}}\). Then by Ohm's law, the current is

\({\rm{Y = }}{{\rm{X}}_{\rm{4}}}\left( {\frac{{\rm{1}}}{{{{\rm{X}}_{\rm{1}}}}}{\rm{ + }}\frac{{\rm{1}}}{{{{\rm{X}}_{\rm{2}}}}}{\rm{ + }}\frac{{\rm{1}}}{{{{\rm{X}}_{\rm{3}}}}}} \right)\)

Let \({{\rm{\mu }}_{\rm{1}}}{\rm{ = 10}}\)ohms, \({{\rm{\sigma }}_{\rm{1}}}{\rm{ = 1}}{\rm{.0ohm,}}\quad {{\rm{\mu }}_{\rm{2}}}{\rm{ = 15}}\)ohms, \({{\rm{\sigma }}_{\rm{2}}}{\rm{ = 1}}{\rm{.0ohm,}}{{\rm{\mu }}_{\rm{3}}}{\rm{ = 20}}\)ohms, \({{\rm{\sigma }}_{\rm{3}}}{\rm{ = 1}}{\rm{.5ohms,}}{{\rm{\mu }}_{\rm{4}}}{\rm{ = 120\;V}}\),

\({{\rm{\sigma }}_{\rm{4}}}{\rm{ = 4}}{\rm{.0 \backslash mathrm\{ \;V}}\)}. Calculate the approximate expected value and standard deviation of the current (suggested by "6andom Samplings," CHEMTECH, \({\rm{1984: 696 - 697}}\)).

In a famous experiment carried out in 1882, Michelson,and Newcomb obtained 66 observations on the time it took for light to travel between two locations in Washington, D.C. A few of the measurements(coded in a certain manner) were 31, 23, 32, 36, 22, 26, 27, and 31.

a. Why are these measurements not identical?

b. Is this an enumerative study? Why or why not?

The accompanying frequency distribution on depositedenergy (mJ) was extracted from the article 鈥淓xperimentalAnalysis of Laser-Induced Spark Ignition of LeanTurbulent Premixed Flames鈥 (Combustion and Flame,2013: 1414鈥1427).

1.0鈭< 2.0 5 2.0鈭<2.4 11

2.4鈭< 2.6 13 2.6鈭<2.8 30

2.8鈭< 3.0 46 3.0鈭< 3.2 66

3.2鈭<3.4 133 3.4鈭< 3.6 141

3.6鈭< 3.8 126 3.8鈭< 4.0 92

4.0鈭< 4.2 73 4.2鈭< 4.4 38

4.4鈭< 4.6 19 4.6鈭< 5.0 11

a. What proportion of these ignition trials resulted in adeposited energy of less than 3 mJ?

b. What proportion of these ignition trials resulted in adeposited energy of at least 4 mJ?

c. Roughly what proportion of the trials resulted in adeposited energy of at least 3.5 mJ?

d. Construct a histogram and comment on its shape.

The accompanying frequency distribution of fracture strength (MPa) observations for ceramic bars fired in aparticular kiln appeared in the article 鈥淓valuating TunnelKiln Performance鈥 (Amer. Ceramic Soc. Bull., Aug.1997: 59鈥63).

Class81-<83 83-<85 85-<87 87-<89 89-<91

Frequency6 7 17 30 43

Class91-<93 93-<95 95-<97 97-<99

Frequency28 22 13 3

  1. Construct a histogram based on relative frequencies, and comment on any interesting features.
  2. What proportion of the strength observations are at least 85? Less than 95?

c. Roughly what proportion of the observations are less than 90?
