Chapter 1: Q31E (page 29)

The cumulative frequency and cumulative relativefrequency for a particular class interval are the sum offrequencies and relativefrequencies, respectively, forthat interval and all intervals lying below it. If, forexample, there are four intervals with frequencies 9,16, 13, and 12, then the cumulative frequencies are 9,25, 38, and 50, and the cumulative relative frequenciesare .18, .50, .76, and 1.00. Compute the cumulativefrequencies and cumulative relative frequencies for thedata of Exercise 24.

Short Answer

Expert verified

The cumulative frequency and the cumulative relative frequency is,

x

Cumulative frequency

Cumulative Relative Frequency

4000-4200

1

0.01

4200-4400

3

0.03

4400-4600

12

0.12

4600-4800

24

0.24

4800-5000

43

0.43

5000-5200

65

0.65

5200-5400

85

0.85

5400-5600

92

0.92

5600-5800

99

0.99

5800-6000

100

1

Step by step solution

01

Given information

The cumulative frequency and cumulative relative frequency for a particular class interval are the sum of frequencies and relative frequencies, respectively, for that interval and all intervals lying below it.

02

Compute the cumulative frequencies and cumulative relative frequencies

Referring to the exercise 24, we have,

x representing the shear strength (lb) of ultrasonic spot welds.

The table representing the frequency and relative frequency as,

x

Frequency

Relative Frequency

4000-4200

1

0.01

4200-4400

2

0.02

4400-4600

9

0.09

4600-4800

12

0.12

4800-5000

19

0.19

5000-5200

22

0.22

5200-5400

20

0.2

5400-5600

7

0.07

5600-5800

7

0.07

5800-6000

1

0.01

Using the given information, the cumulative frequency and the cumulative relative frequency is represented as,

x

Cumulative frequency

Cumulative Relative Frequency

4000-4200

1

0.01

4200-4400

3

0.03

4400-4600

12

0.12

4600-4800

24

0.24

4800-5000

43

0.43

5000-5200

65

0.65

5200-5400

85

0.85

5400-5600

92

0.92

5600-5800

99

0.99

5800-6000

100

1

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Blood cocaine concentration (mg/L) was determined both for a sample of individuals who had died from cocaine-induced excited delirium (ED) and for a sample of those who had died from a cocaine overdose without excited delirium; survival time for people in both groups was at most 6 hours. The accompanying data was read from a comparative boxplot in the article 鈥淔atal Excited Delirium Following Cocaine Use鈥� (J.

of Forensic Sciences, 1997: 25鈥�31).

ED0 0 0 0 .1 .1 .1 .1 .2 .2 .3 .3

.3 .4 .5 .7 .8 1.0 1.5 2.7 2.8

3.5 4.0 8.9 9.2 11.7 21.0

Non-ED0 0 0 0 0 .1 .1 .1 .1 .2 .2 .2

.3 .3 .3 .4 .5 .5 .6 .8 .9 1.0

1.2 1.4 1.5 1.7 2.0 3.2 3.5 4.1

4.3 4.8 5.0 5.6 5.9 6.0 6.4 7.9

8.3 8.7 9.1 9.6 9.9 11.0 11.5

12.2 12.7 14.0 16.6 17.8

a. Determine the medians, fourths, and fourth spreads for the two samples.

b. Are there any outliers in either sample? Any extreme outliers?

c. Construct a comparative boxplot, and use it as a basis for comparing and contrasting the ED and non-ED samples.

An experiment to study the lifetime (in hours) for acertain type of component involved putting ten components into operation and observing them for 100hours. Eight of the components failed during that

period, and those lifetimes were recorded. Denote the lifetimes of the two components still functioning after100 hours by 100+. The resulting sample observations were

48 79 100+ 35 92 86 57 100+ 17 29

Which of the measures of center discussed in this section can be calculated, and what are the values of those measures? (Note:The data from this experiment is said to be 鈥渃ensored on the right.鈥�)

The amount of flow through a solenoid valve in an automobile鈥檚

pollution-control system is an important characteristic. An experiment was carried out to study how flow rate depended on three factors: armature length, spring load, and bobbin depth. Two different levels (low and high) of each factor were chosen, and a single observation on flow was made for each combination oflevels.

a. The resulting data set consisted of how manyobservations?

b. Is this an enumerative or analytic study? Explainyour reasoning.

Automated electron backscattered diffraction is now being used in the study of fracture phenomena. The following information on misorientation angle (degrees) was extracted from the article 鈥淥bservations on the Faceted Initiation Site in the Dwell-Fatigue Tested Ti-6242 Alloy: Crystallographic Orientation and Size Effects鈥� (Metallurgical and Materials Trans., 2006: 1507鈥�1518).

Class: 0-<5 5-<10 10-<15 15-<20

Relfreq: .177 .166 .175 .136

Class: 20-<30 30-<40 40-<60 60-<90

Relfreq: .194 .078 .044 .030

a. Is it true that more than 50% of the sampled angles are smaller than 15掳, as asserted in the paper?

b. What proportion of the sampled angles are at least 30掳?

Suppose your waiting time for a bus in the morning is uniformly distributed on\((0,8)\), whereas waiting time in the evening is uniformly distributed on\((0,10)\)independent of the morning waiting time.

a. If you take the bus each morning and evening for a week, what is your total expected waiting time?

b. What is the variance of your total waiting time?

c. What are the expected value and variance of the difference between morning and evening waiting times on a given day?

d. What are the expected value and variance of the difference between total morning waiting time and total evening waiting time for a particular week?
