The total scoring alignment is the cost of editing the strings using insertion, deletion, or gap penalties.

Suppose the given strings are $x=x_1,x_2,K{x}_{n}andy=y_1,y_2,K{y}_m$.

The first step is to determine the similarity score of the elements$未\left(a,b\right)$ and the gap penalty of length k.

In the next step the first row and column of the scoring matrix M of size role="math" localid="1658918665081" $\left(n+1\right)$times $\left(m+1\right)$to zero Then in the next step, the scoring matrix is filled.

Then tracing back from the highest score to zero in the scoring matrix gives the best alignment.

Algorithm:

The algorithm can be written as given below:

$未\left(a,b\right)$- score

$G_k$- gap penalty of length k

$M\left[n+1\right]\left[m+1\right]$- scoring matrix

for $o=0ton$

$M\left[0\right]\left[1\right]=0$

for o=0 to m

$M\left[1\right]\left[0\right]=0$

for o=1 to n

for p=1 to n

$$\begin{gathered} M\left[o\right]\left[p\right]=max\left[1\right] \\ M\left[o-1\right]\left[p-1\right]+未\left(a_o,b_p\right) \\ max\left\{k_1,M\left[o-k\right]\left[p\right]-G_k\right\} \\ max\left\{l_1,M\left[o\right]\left[p-1\right]-G_k\right\} \end{gathered}$$

Traceback from highest alignment score to 0.

Explanation:

$M\left[o\right]\left[p\right]$is a optimal score of aligning.

There are only a polynomial number of subproblems.

Every subproblems can be solved easily by solving smaller subproblems.

See, in step-7 we have three cases. first case is $x_o=y_p$second case is, $x_o$ aligns to a gap and, third case is $y_p$aligns to a gap.

The calculated scoring matrix is of size

So, the complexity of the program is $O\left(nm\right)o=$
