The standard cell potential or $E_{cell}$is defined as the cell potential when the concentration of the species in solution is 1M. Mathematically it can be calculated as the difference of the electrode half-cell.

${\text{E}}_{\text{cell}}°={\text{E}}_{\text{cathode}}°{\text{- E}}_{\text{anode}}°$

The Nernst equation establishes a relation between the cell potential under non-standard condition and concentration of the species in the solution. The Nernst equation is given below.

${\text{E}}_{\text{cell}}={\text{E}}_{\text{cell}}^{\text{o}}\text{-}\frac{\text{RT}}{\text{nF}}\text{lnQ}$

We will consult appendix D for the electrode potential of the half-cell.

• Electrode potential of $Ni/N{i}^{2+}={E^{∘}}_{Ni/N{i}^{2+}}=-0.25V$.
• Electrode potential of $C{o}^{+2}/Co={E^{∘}}_{C{o}^{+2}/Co}=-0.28V$.

Since,${E^{∘}}_{C{o}^{2+}/Co}<{E^{∘}}_{N{i}^{+2}/Ni}$, will be cathode and $C{o}^{+2}/Co$will be anode.

We will write down the half-cell reaction and calculate the standard cell potential,

$$\begin{gathered} \text{Cathode}  \text{reaction}    {\text{Ni}}^{2+}\left(\text{aq}\right)+2{\text{e}}^{-}→\text{Ni}\left(\text{s}\right) \\ \text{Anode}  \text{reaction}        \text{Co}\left(\text{s}\right)→{\text{Co}}^{+2}\left(\text{aq}\right){\text{+ 2e}}^{\text{-}} \end{gathered}$$

Overall reaction ${\text{Ni}}^{2+}\left(\text{aq}\right)+\text{Co}\left(\text{s}\right)→\text{Ni}\left(\text{s}\right)+{\text{Co}}^{2+}\left(\text{aq}\right)$

$$\begin{gathered} {E^{∘}}_{cell}={E^{∘}}_{reduction}-{E^{∘}}_{oxidation} \\ {E^{∘}}_{cell}={E^{∘}}_{N{i}^{+2}/Ni}-{E^{∘}}_{C{o}^{+2}/Co} \\ {E^{∘}}_{cell}=-0.25V-\left(-0.28\right)V \\ {E^{∘}}_{cell}=0.03V \end{gathered}$$.

a.

We know that,

$$\begin{gathered} E_{cell}={E^{∘}}_{cell}-\frac{0.0592}{n}\log Q \\ {E}_{cell}=0.03-\frac{0.0592}{2}\log \frac{\left[C{o}^{2+}\right]}{\left[N{i}^{2+}\right]} \\ {E}_{cell}=0.03-0.0296\log \frac{0.20M}{0.80M} \\ {E}_{cell}=0.03-0.0296×-0.60 \\ {E}_{cell}=0.03+0.017 \\ {E}_{cell}=0.048 \end{gathered}$$

Hence initial $E_{cell}=0.048$

b.

$$\begin{gathered} E_{cell}=0.03 \\ {E^{∘}}_{cell}=0.03 \end{gathered}$$

$$\begin{gathered} E_{cell}={E^{∘}}_{cell} \\ 0.03=0.03-\frac{0.0592}{2}\log \frac{\left[C{o}^{2+}\right]}{\left[N{i}^{2+}\right]} \\ 0=-0.0296\log \frac{0.20M}{\left[N{i}^{2+}\right]} \\ 0=-\log \frac{0.20M}{\left[N{i}^{2+}\right]} \\ {10}^0=1=\frac{\left[N{i}^{2+}\right]}{0.20M} \\ \left[N{i}^{2+}\right]=\frac{1}{0.20M} \\ \left[N{i}^{2+}\right]=0.50M \end{gathered}$$

Hence, $\left[N{i}^{2+}\right]=0.50M$.

c.

Equilibrium concentrations of ions.

${\text{Ni}}^{2+}\left(\text{aq}\right)+\text{Co}\left(\text{s}\right)→\text{Ni}\left(\text{s}\right)+{\text{Co}}^{2+}\left(\text{aq}\right)$

We will prepare an ICE table for the equilibrium concentrations of the respective ions.

At equilibrium;

$$\begin{gathered} E_{cell}={E^{∘}}_{cell}-\frac{0.0592}{n}\log Q \\ 0=0.03-\frac{0.0592}{2}\log \frac{\left[C{o}^{2+}\right]}{\left[N{i}^{2+}\right]} \\ -0.03=-0.0296\log \frac{0.02+X}{0.8-X} \\ 1.01=\log \frac{0.02+X}{0.8-X} \\ 10.23×\left(0.8-X\right)=0.2+X \\ 8.19-10.23X=0.2+X \\ 7.99=11.23X \\ X=0.71 \end{gathered}$$

Therefore, at equilibrium

(a)$\left[{\text{Ni}}^{\text{2 +}}\right]\text{= [initital - X] = 0.8 - 0.71 = 0.09M}$

(b)$\left[{\text{Co}}^{\text{2 +}}\right]\text{= [initital + X] = 0.2 + 0.71 = 0.91M}$
