For an oscillatory motion, if the restoring force is directly proportional to the displacement of particle from its mean position. Thenthe motion is called simple harmonic motion.

The maximum velocity of a system undergoing simple harmonic motion is $v_{\max }=2\mathrm{Ï€}fA$

where $v_{\max }$is the maximum speed, f is the frequency and A is amplitude.

Frequency heard by the listener, directly over the siren, is

$f_L=f_s\left(\frac{v}{v∓v_{\max }}\right)$

Now,$f_L$will be maximum when the sign in the denominator is minus, which leads to

$f_{L\max }=f_{siren}\left(\frac{v}{v−2\mathrm{π}fA}\right)$

On the other hand,$f_L$ will be minimum when the sign in the denominator is plus, meaning a larger denominator, which leads to

$f_{L\min }=f_{siren}\left(\frac{v}{v+2\mathrm{Ï€}fA}\right)$

Therefore, the maximum frequency is detected when the platform reaches its maximum velocity and moving towards the listener, which happens when the platform is passing through the equilibrium position and moving up. In the same way, the minimum frequency is detected when the platform is at its edges, moving down.
