Chapter 1: 11 (page 27)

A circular racetrack has a radius of 500 m. What is the displacement of a bicyclist when she travels around the track from the north side to the south side? When she makes one complete circle around the track? Explain.

Short Answer

Expert verified

Displacement of bicyclist in case I is 1000 m and case II is zero.

Step by step solution

01

Given Data:

The radius of racetrack is r=500 m.

02

Displacement

In Simple words displacement is the shortest distance travelled by an object.

Here in first casebicyclistis travelling from A to B that is a semicircle.

So, the distance traveled by thebicyclistwill be 蟺搁.

Now the displacementtraveledis the minimum distance between point A and B that is diameter AB.

Displacement=AB=2R=2500m=1000m

Thus, the displacement is 1000 m.

03

Displacement in Case II

When the body is completing one full rotation the distance traveled by the body is 2蟺搁.

The displacementtraveledwill be the minimium distance between point A and B.

As it completes one circle the point A and B will be same .

So, the displacement between the points will bezero.

Therefore, displacement of bicyclist in case II is zero.
