Chapter 4: Q34E (page 843)

When a resistor with resistance Ris connected to a 1.50-V flashlight battery, the resistor consumes 0.0625 W of electrical power. (Throughout, assume that each battery has negligible internal resistance.) (a) What power does the resistor consume if it is connected to a 12.6-V car battery? Assume that Rremains constant when the power consumption changes. (b) The resistor is connected to a battery and consumes 5.00 W. What is the voltage of this battery?

Short Answer

Expert verified
  1. The power consumed by the resistor when connected to 12.6 V car battery is 4.41W
  2. The voltage of the battery is 13.4V .

Step by step solution

01

  (a) Determination of the power consumed by the resistor when connected to 12.6 V car battery.

The resistance is constant in both cases, and the expression of power is

p=V2R

Rearrange for R,

p=V2R

So, for equal resistance,

V12P1=V12P2....(1)SolveforP2,P2=V22P1V125

Substitute all the values in the above equation,

P2=(0.0625W)12.5V1.50V2=4.41W

02

(b) Determination of the voltage of the battery.

From equation (i), Solve for V2 as,

V12P1=V22P2V2=V1P2P1

Substitute all the values in the above equation,

V2=(1.50V)5.00W0.0625W=13.4VThus,thevoltageis13.4V.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Each of the lettered points at the corners of the cube in Fig. Q27.12 represents a positive charge qmoving with a velocity of magnitude vin the direction indicated. The region in the figure is in a uniform magnetic field , parallel to the x-axis and directed toward the right. Which charges experience a force due to B鈬赌? What is the direction of the force on each charge?

Why does an electric light bulb nearly always burn out just as you turn on the light, almost never while the light is shining?

In the circuit shown in Fig. E26.47 each capacitor initially has a charge of magnitude 3.50 nC on its plates. After the switch S is closed, what will be the current in the circuit at the instant that the capacitors have lost 80.0% of their initial stored energy?
