Chapter 4: Q17E (page 948)

The body contains many small currents caused by the motion of ions in the organs and cells. Measurements of the magnetic field around the chest due to currents in the heart give values of about10渭G . Although the actual currents are rather complicated, we can gain a rough understanding of their magnitude if we model them as a long, straight wire. If the surface of the chest is 5 cm from this current, how large is the current in the heart?

Short Answer

Expert verified

The magnitude of the current is2.5脳10-4A .

Step by step solution

01

Formula of magnetic field

Treat the wire as a very long wire in this case.

Magnetic field due to a very long wire is given byB=渭0I2蟺谤 .

02

Calculate the current

Given thatB=10渭G andr=5cm . The current is given by

I=2蟺rB渭0I=2蟺脳0.05脳10鈭�94蟺脳10鈭�7I=2.5脳10鈭�4A

So, the magnitude of the current is2.5脳10-4A .

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Copper has 8.5脳1022free electrons per cubic meter. A 71.0-cm

length of 12-gauge copper wire that is 2.05 mm in diameter carries 4.85 A of

current. (a) How much time does it take for an electron to travel the length

of the wire? (b) Repeat part (a) for 6-gauge copper wire (diameter 4.12 mm)

of the same length that carries the same current. (c) Generally speaking,

how does changing the diameter of a wire that carries a given amount of

current affect the drift velocity of the electrons in the wire?


An electron at pointAinFig. E27.15has a speedv0of1.41脳106m/sFind (a) the magnitude and direction of the magnetic field that will cause the electron to follow the semicircular path fromAtoB, and (b) the time required for the electron to move fromAtoB.

An electron moves at 1.40脳106m/sthrough a regionin which there is a magnetic field of unspecified direction and magnitude 7.40脳10-2T. (a) What are the largest and smallest possible magnitudes of the acceleration of the electron due to the magnetic field? (b) If the actual acceleration of the electron is one-fourth of the largest magnitude in part (a), what is the angle
between the electron velocity and the magnetic field?

When a resistor with resistance Ris connected to a 1.50-V flashlight battery, the resistor consumes 0.0625 W of electrical power. (Throughout, assume that each battery has negligible internal resistance.) (a) What power does the resistor consume if it is connected to a 12.6-V car battery? Assume that Rremains constant when the power consumption changes. (b) The resistor is connected to a battery and consumes 5.00 W. What is the voltage of this battery?

In the circuit shown in Fig. E26.41, both capacitors are initially charged to 45.0 V. (a) How long after closing the switch S will the potential across each capacitor be reduced to 10.0 V, and (b) what will be the current at that time?
