Magazine Chapter 8: Q 26P (page 198)
A person exerts a horizontal force of 42 N on the end of a door 96 cm wide. What is the magnitude of the torque if the force is exerted (a) perpendicular to the door and (b) at a 60.0掳 angle to the face of the door?
Short Answer
- The torque exerted when\(\theta = {90^{\rm{o}}}\)is 40.32 m N.
- The torque exerted when \(\theta = {60^{\rm{o}}}\) is 35 m N.
Step by step solution
Identification of the given data
The magnitude of the force is \(F = 42\;{\rm{N}}\).
The width of the door is \(r = 96\;{\rm{cm}} = 0.96\;{\rm{m}}\).
Definition of torque
Torque is defined as the measure of the force that causes an object to rotate about an axis. It is also called the rotational equivalent of linear force.
Mathematically, torque is represented as follow:
\(\begin{align}\vec \tau &= \vec r \times \vec F\\\left| \tau \right| &= rF\sin \theta \end{align}\) 鈥� (i)
Here, F is the applied force, and r is the perpendicular distance between the point about which the torque is calculated and the point of application of force.
(a) Determination of the torque when the force is perpendicular to the door
When the force exerted is perpendicular to the door, the angle is \(\theta = {90^{\rm{o}}}\).
From equation (i),
\(\begin{align}\tau & = rF\sin {90^{\rm{o}}}\\ &= \left( {0.96\;{\rm{m}}} \right)\left( {42\;{\rm{N}}} \right)\\ &= 40.32\;{\rm{m}}\;{\rm{N}}\end{align}\)
(b) Determination of the torque when the force is exerted at an angle of 60°
When the force exerted is at \(\theta = {60^{\rm{o}}}\) to the face of the door,
\(\begin{align}\tau &= rF\sin {60^{\rm{o}}}\\ &= \left( {0.96\;{\rm{m}}} \right)\left( {42\;{\rm{N}}} \right)\frac{{\sqrt 3 }}{2}\\ \approx 35\;{\rm{m}}\;{\rm{N}}\end{align}\)
