Chapter 8: 8-16P (page 198)

A turntable of radius is turned by a circular rubber roller of radius in contact with it at their outer edges. What is the ratio of their angular velocities,\({\omega _1}/{\omega _2}\)?

Short Answer

Expert verified

The ratio of the angular velocities is\(\frac{{{\omega _1}}}{{{\omega _2}}} = \frac{{{R_2}}}{{{R_1}}}\).

Step by step solution

01

Given data

The radius of the turntable is\({R_1}\).

The radius of the roller is\({R_2}\).

02

Understanding angular velocities

When there is no slipping between the turntable and the rubber roller, the tangential speed of the table will be equivalent to the tangential speed of the roller.

03

Determine the ratio of the angular velocities

Since the speeds of the roller and table are similar, the relation to calculate the ratio of the angular velocities is given as follows:

\(\begin{aligned}{c}{v_1} &= {v_2}\\{\omega _1}{R_1} &= {\omega _2}{R_2}\\\frac{{{\omega _1}}}{{{\omega _2}}} &= \frac{{{R_2}}}{{{R_1}}}\end{aligned}\)

Thus, \(\frac{{{\omega _1}}}{{{\omega _2}}} = \frac{{{R_2}}}{{{R_1}}}\) is the required ratio.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

A hammer thrower accelerates the hammer\(\left( {{\bf{mass}} = {\bf{7}}{\bf{.30 kg}}} \right)\)from rest within four full turns (revolutions) and releases it at a speed of\({\bf{26}}{\bf{.5 m/s}}\).Assuming a uniform rate of increase in angular velocity and a horizontal circular path of radius 1.20 m, calculate (a) the angular acceleration, (b) the (linear) tangential acceleration, (c) the centripetal acceleration just before release, (d) the net force being exerted on the hammer by the athlete just before release, and (e) the angle of this force with respect to the radius of the circular motion. Ignore gravity.

A softball player swings a bat, accelerating it from rest to 2.6 rev/s in a time of 0.20 s. Approximate the bat as a 0.90-kg uniform rod of length 0.95 m, and compute the torque the player applies to one end of it.

A centrifuge rotor rotating at 9200 rpm is shut off and eventually brought uniformly to rest by a frictional torque of \({\bf{1}}{\bf{.20}}\;{\bf{m}} \cdot {\bf{N}}\). If the mass of the rotor is 3.10 kg, and it can be approximated as a solid cylinder of radius 0.0710 m, through how many revolutions will the rotor turn before coming to rest, and how long will it take?

Bonnie sits on the outer rim of a merry-go-round, and Jill sits midway between the centre and the rim. The merry-go-round makes one complete revolution every 2 seconds. Jill鈥檚 linear velocity is:

(a) the same as Bonnie鈥檚.

(b) twice Bonnie鈥檚.

(c) half of Bonnie鈥檚.

(d) one-quarter of Bonnie鈥檚.

(e) four times Bonnie鈥檚.

The tires of a car make 75 revolutions as the car reduces its speed uniformly from 95 km/h to 55 km/h. The tires have a diameter of 0.80 m. (a) What was the angular acceleration of the tires? If the car continues to decelerate at this rate, (b) how much more time is required for it to stop, and (c) how far does it go?
