Figure 6.76 shows the path of a comet orbiting a star.

(a) Rank-order the locations on the path in terms of the magnitude of the comet鈥檚 momentum at each location, starting with the location at which the magnitude of the momentum is the largest. (b) Rank-order the locations on the path in terms of the comet鈥檚 kinetic energy at each location, starting with the location at which the kinetic energy is the largest. (c) Rank-order the locations on the path in terms of the potential energy of the system at each location, largest first. (d) Rank-order the locations on the path in terms of the sum of the kinetic energy and the potential energy of the system at each location, largest first

Short Answer

Expert verified

(a) The order of the locations on the path in terms of the magnitude of the comet鈥檚 momentum at each location, starting with the location at which the magnitude of the momentum is the largest is E>D>C>B>A.

(b) The order of the kinetic energy from largest to least is E>D>C>B>A.

(c) The order of the locations on the path in terms of the potential energy of the system at each location from largest to least is A>B>C>D>E.

(d) The order the locations on the path in terms of the sum of the kinetic energy and the potential energy of the system at each location from largest to least is A=B=C=D=E.

Step by step solution

01

Identification of given data

The given data can be listed below,

  • The comet is orbiting around a star.

02

Concept/Significance of potential energy

Potential energy is related to unbalanced forces poised to perform work, while kinetic energy is linked with momentum.

Energy, like momentum, is preserved, but it has a different form known as potential energy. The kinetic and potential energies are not preserved independently.

03

Evaluation of Rank-order the locations on the path in terms of the magnitude of the comet’s momentum at each location.

(a)

The momentum of comet is given by,

p=mv

Here,mis the mass of the comet,vis the velocity of the comet.

When comet is near the star its speed will increase as the distance between them decreases.

Following the diagram,Ehave greatest speed because its nearer to the star, the momentum is directly proportional to velocity so the momentum will be greatest at pointEfollowed by,D,C,B, andArespectively.

Thus, the order of the locations on the path in terms of the magnitude of the comet鈥檚 momentum at each location, starting with the location at which the magnitude of the momentum is the largest is E>D>C>B>A.

04

Evaluation of the Rank-order of the locations on the path in terms of the comet’s kinetic energy at each location.

(b)

The kinetic energy of the comet is given by,

K.E=12mv2

Here,mis the mass of the comet,vis the velocity of the comet.

From above equation, the kinetic energy of the comet is directly proportional to the velocity of the comet.

So, the kinetic energy of the point having greatest velocity will be maximum. From (a)

It is found that the velocity and momentum f the pointEis highest.

Thus, the order of the kinetic energy from largest to least is E>D>C>B>A.

05

Evaluation of the order the locations on the path in terms of the potential energy of the system at each location

(c)

The gravitational potential energy of the comet is given by,

U=-GMmr

Here, G is the gravitational constant whose value is 6.67310-11Nm2/kg2, m is the mas of the comet, M is the mass of the star, r is the distance between comet and star.

The potential energy is inversely proportional torwith negative sign.

U-1r

From above equation, it is seen that the potential energy will increase with increase in distance between star and comet. So, distance between comet and star is greatest at pointAfollowed byB, C, DandE.

Thus, the order of the locations on the path in terms of the potential energy of the system at each location from largest to least is A>B>C>D>E.

06

Evaluation of the order the locations on the path in terms of the sum of the kinetic energy and the potential energy of the system at each location

(d)

The total energy of the comet is given by,

E=12mv2-GMmr

From law of conservation of the energy,

12mv2=GMmr

From equation it is determined that the energy is equal and constant at all the points of the system.

Thus, the order the locations on the path in terms of the sum of the kinetic energy and the potential energy of the system at each location from largest to least is A=B=C=D=E.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

(a)Two protons are a distance 410-9mapart. What is the electric potential energy of the system consisting of the two protons? If the two protons move closer together, will the electric potential energy of the system increase, decrease or remain the same? (b) A proton and an electron are a distance 410-9mapart. What is the electric potential energy of the system consisting of the proton and the electron? If the proton and the electron move closer together, will the electric potential energy of the system increase, decrease or remain the same? (c) Which of the following statements are true? A. In some situations, charged particles released from rest would move in a direction that increases electric potential energy, but not in other situations. B. If released from rest, two protons would move closer together, increasing the potential energy of the system. C. If any two charged particles are released from rest, they will spontaneously move in the direction in which the potential energy of the system will be decreased.

The Four protons, each with mass Mand charge te, are initially held at the corners of a square that is don a side. They are then released from rest. What is the speed of each proton when the protons are very far apart?

A nucleus whose mass is 3.49961210-25kgundergoes spontaneous alpha decay. The original nucleus disappears and there appear two new particles: a He-4 nucleus of mass 6.64067810-27kg(an 鈥渁lpha particle鈥 consisting of two protons and two neutrons) and a new nucleus of mass3.43313210-25kg (note that the new nucleus has less mass than the original nucleus, and it has two fewer protons and two fewer neutrons). (a) When the alpha particle has moved far away from the new nucleus (so the electric interactions are negligible), what is the combined kinetic energy of the alpha particle and new nucleus? (b) How many electron volts is this? In contrast to this nuclear reaction, chemical reactions typically involve only a few eV.

A pendulum (see Figure 6.84) consists of a very light but stiff rod of length Lhanging from a nearly frictionless axle, with a mass mat the end of the rod.

(a) Calculate the gravitational potential energy as a function of the angle , measured from the vertical.

(b) Sketch the potential energy as a function of the angle , for angles from -210to -210.

(c) Let =L=the arc length away from the bottom of the arc. Calculate the tangential component of the force on the mass by taking the (negative) gradient of the energy with respect to s. Does your result make sense?

(d) Suppose that you hit the stationary hanging mass so it has an initial speed v1.

What is the minimum initial speed needed for the pendulum to go over the top =180? On your sketch of the potential energy (part b), draw and label energy levels for the case in which the initial speed is less than, equal to, or greater than this critical initial speed.


One mole of helium atoms has a mass of 4grams. If a helium atom in a balloon has a kinetic energy of1.43710-21J, what is the speed of the helium atom? (The speed is much lower than the speed of light.)?
