What are the magnitude and direction of the electric field E→at location <20,0,0>cmif there is a negative point charge of 1nC(1×10-9C)at location<40,0,0>cm? Include units.

Short Answer

Expert verified

The magnitude of the electric field is -225,0,0N/Cand its direction is negative.

Step by step solution

01

Identification of given data

The given data is listed below as:

  • The Value of the negative point charge is,q=1×10-9C
  • The position of the electric field is,r2=20,0,0cm
  • The position of charge is,r1=40,0,0cm
02

Definition of Electric field for charge particle

The electric field is described as a region which helps a charged particle to exert force on another charged particle.

The electric field inside a sphere having uniform charge is expressed as:

E=14πε0-q|r→|r^ …(¾±)

Here,qis the charge of the sphere,14πε0is the electric field constant with value 9×109N.m2/C,|r→|is the magnitude of the position vector andr^is the unit vector.

03

Calculation of the unit vector

The equation of the value of the position vector is expressed as:

r→=r2-Ir

Here,r1is the location of the charge and r2is the position of the electric field.

Substitute the values in the above equation.

r→=20,0,0cm-40,0,0cm=-20,0,0cm

The equation of the magnitude of the position magnitude of vector is expressed as:

r→=X12+y12+Z12

Here,x1is the position of the point in the xcoordinate, y1is the position of the point in the ycoordinate and role="math" localid="1656919307064" z1is the position of the point in the z coordinate.

Substitute the values in the above equation.

r→=202+02+02cm

The equation of the unit vector is expressed as:

r^=r→r→

Here,r→is the position vector and r→is the magnitude of the position vector.

Substitute the values in the above equation.

r^=-20,0,0cm20cm=-1,0,0

04

Determination of the electric field

Substitute all the values in the equation (i).

E=9×109N.m2/C21×10-9C20cm×1m100cm2-1,0,0=9N.m2/C0.04m2-1,0,0=225N/C×-1,0,0=-225,0,0N/C

Thus, the magnitude the electric field is -225,0,0N/C.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

A particle with charge +1nC (a nanocoulomb is 1X10-9C) is located at the origin. What is the electric field due to this particle at a location <0.1,0,0>m?

In Figure 13.66 a proton at location A makes an electric field E→1at location B. A different proton, placed at location B, experiences a force F→1. Now the proton at B is removed and replaced by a lithium nucleus, containing three protons and four neutrons. (a) Now what is the value of the electric field at location B due to the proton? (b) What is the force on the lithium nucleus? (c) The lithium nucleus is removed, and an electron is placed at location B. Now what is the value of the electric field at location B due to the proton? (d) What is the magnitude of the force on the electron? (e) Which arrow in Figure 13.65 best indicates the direction of the force on the electron due to the electric field?
