A student claimed that the equation for the electric field outside a cube of edge length L, carrying a uniformly distributed charge Q, at a distance x from the center of the cube, was

14o50QLx3

Explain how you know that this cannot be the right equation.

Short Answer

Expert verified

Answer

The equation should produce the electric field for a point charge for a large distance of the cube from the center of the electric field, but it cannot produce the equation.

Step by step solution

01

Identification of given data

The given data is listed below as:

  • The edge length of the cube is, L

  • The charge of the cube is, Q

  • The distance of the cube from the center is, x

02

Significance of the magnitude of the electric field

The electric field helps an electrically charged particle to exert force on another particle. The magnitude of the electric field is inversely proportional to the distance of the charged object from the electric field and directly proportional with the charge of that object.

03

Determination of the correctness of the equation

The equation of the magnitude of the electric field given in the question is expressed as:

E=14050QLx3

Here, 14蟺蔚0is the electric field constant, Qis the charge of the cube, Lis the length of the cube and xis the distance of the cube from the center of the electric field.

The equation of the magnitude of the electric field for a point charge is expressed as:

E1=14蟺蔚0qr2

Here, 14蟺蔚0is the electric field constant, qis the charge of an object and ris the distance of the object from the center of the electric field.

The expression given in the question is wrong as at a certain distance from the cube, the electric field is approximately same as the electric field having a point charge, but the field is not same.

Thus, the equation should produce the electric field for a point charge for a large distance of the cube from the center of the electric field, but it cannot produce the equation.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Question: Breakdown field strength for air is roughly . If the electric field is greater than this value, the air becomes a conductor. (a) There is a limit to the amount of charge that you can put on a metal sphere in air. If you slightly exceed this limit, why would breakdown occur, and why would the breakdown occur very near the surface of the sphere, rather than somewhere else? (b) How much excess charge can you put on a metal sphere of radius without causing breakdown in the neighboring air, which would discharge the sphere? (c) How much excess charge can you put on a metal sphere of onlyradius? These results hint at the reason why a highly charged piece of metal tends to spark at places where the radius of curvature is small, or at places where there are sharp points.

A thin rod lies on the x axis with one end atand the other end at-A, as shown in Figure 15.51. A charge of-Q
is spread uniformly over the surface of the rod. We want to set up an integral to find the electric field at location <0,Y,0>due to the rod. Following the procedure discussed in this chapter, we have cut up the rod into small segments, each of which can be considered as a point charge. We have selected a typical piece, shown in red on the diagram

Answer using the variables x,y,dx,A,Qas appropriate. Remember that the rod has charge-Q. (a) In terms of the symbolic quantities given above and on the diagram, what is the charge per unit length of the rod? (b) What is the amount of chargedQon the small piece of lengthdx? (c) What is the vector from this source to the observation location? (d) What is the distance from this source to the observation location? (e) When we set up an integral to find the electric field at the observation location due to the entire rod, what will be the integration variable?

Two rings of radius 2 cm are 20 cm apart and concentric with a common horizontal x axis. What is the magnitude of the electric field midway between the rings if both rings carry a charge of +35 nC?

Consider a thin glass rod of length L lying along the x axis with one end at the origin. The rod carries a uniformly distributed positive charge Q.

At a location d > L, on the x axis to the right of the rod in Figure 15.56, what is the electric field due to the rod? Follow the standard four steps. (a) Use a diagram to explain how you will cut up the charged rod, and draw the contributed by a representative piece. (b) Express algebraically the contribution each piece makes to the electric field. Be sure to show your integration variable and its origin on your drawing. (c) Write the summation as an integral, and simplify the integral as much as possible. State explicitly the range of your integration variable. Evaluate the integral. (d) Show that your result is reasonable. Apply as many tests as you can think of

An electrostatic dust precipitator that is installed in a factory smokestack includes a straight metal wire of length L=0.8 mthat is charged approximately uniformly with a total charge Q=0.410-7C . A speck of coal dust (which is mostly carbon) is near the wire, far from both ends of the wire; the distance from the wire to the speck is d=1.5 cm . Carbon has an atomic mass of 12( 6protons and 6neutrons in the nucleus). A careful measurement of the polarizability of a carbon atom gives the value

=1.9610-40CmN/C

(a) Calculate the initial acceleration of the speck of coal dust, neglecting gravity. Explain your steps clearly. Your answer must be expressed in terms ofQ,L,d,and . You can use other quantities in your calculations, but your final result must not include them. Don鈥檛 put numbers into your calculation until the very end, but then show the numerical calculation that you carry out on your calculator. It is convenient to use the 鈥渂inomial expansion鈥 that you may have learned in calculus, that(1+)n1+苍蔚is 1. Note thatcan be negative. (b) If the speck of coal dust were initially twice as far from the charged wire, how much smaller would be the initial acceleration of the speck?
