• Intensity level ,${\mathrm{β}}_1=8\text{5dB}$
• Other intensity level ,${\mathrm{β}}_2=65\text{dB}$
• Distance ,$\mathrm{r}=10\text{m}$

Write the sound level in terms of intensity. Also, write the relation between intensity, power, and radius. Substituting the intensity in terms of power in the formula for sound intensity, and using the data from the given graph, find the ratio of the power. Also, see the difference between the intensity values at any given radius from the graph and compare it to the value asked in the problem.

The expression for the intensity in terms of power is given by,

$\mathrm{I}=\frac{\mathrm{P}}{4{\mathrm{Ï€°ù}}^2}$

Here $P$is the power, $I$is the intensity,$\mathrm{r}$ is the radius.

The expression for the sound level is given by,

${\mathrm{β}}_1−{\mathrm{β}}_2=10\log \left(\frac{{\mathrm{I}}_1}{{\mathrm{I}}_2}\right)$

Here, ${\mathrm{β}}_1$,${\mathrm{β}}_2$ are the sound level, $I_1$, $I_2$are the intensities.

Sound level can be written as,

$\mathrm{β}=10\log \left(\frac{\mathrm{I}}{{\mathrm{I}}_0}\right)$

Since,

${\mathrm{β}}_1−{\mathrm{β}}_2=10\log \left(\frac{{\mathrm{I}}_1}{{\mathrm{I}}_0}\right)−10\log \left(\frac{{\mathrm{I}}_2}{{\mathrm{I}}_0}\right)$

Now,

$\mathrm{I}=\frac{\mathrm{P}}{4{\mathrm{Ï€°ù}}^2}$

${\mathrm{β}}_1−{\mathrm{β}}_2=10\log \left(\frac{{\mathrm{P}}_1}{{\mathrm{P}}_2}\right)$

At any given radius r, the difference between sound levels, $\mathrm{Δβ}={\mathrm{β}}_1−{\mathrm{β}}_2$is $\text{5.0dB}$, therefore,

$\begin{array}{c}5.0=10\log \left(\frac{{\mathrm{P}}_1}{{\mathrm{P}}_2}\right)\\ 0.5=\log \left(\frac{{\mathrm{P}}_1}{{\mathrm{P}}_2}\right)\\ \frac{{\mathrm{P}}_1}{{\mathrm{P}}_2}={10}^{0.5}\\ =3.16\\ ≈3.2\end{array}$

Hence, the ratio of larger to lower power is$3.2$ .

From the graph, it can be seen that the sound level difference is constant between the two sources for all the values of $\mathrm{r}$ . Therefore, for role="math" localid="1661410281447" $r=10\text{ }m$, it would be equal to $\text{5.0dB}$.

Hence, the sound level difference is $\text{5.0dB}$.

Therefore, using the relationship between power, intensity, and sound level, the ratio can be found. Also, the sound level at any other radius can be found using the data from the graph.
