A wheel, starting from rest, rotates with a constant angular acceleration of 2.00rad/s2. During a certain 3.00sinterval, it turns through 90.0rad. (a) What is the angular velocity of the wheel at the start of the3.00sinterval? (b) How long has the wheel been turning before the start of the3.00sinterval?

Short Answer

Expert verified
  1. The angular velocity of the wheel at start of the interval is27rad/s
  2. The time for which wheel has been turning before the start of the 3.00sinterval is13.5s

Step by step solution

01

Given

θf-θ0=90radα=2.0rads2t=3.0s

02

Understanding the concept

Using the second kinematic equation of rotational motion, we can find the angular velocity of the wheel at the start of interval. Using this angular velocity into the formula of angular acceleration, we can find the time for which the wheel has been turning before the start of the i3.00snterval.

Formula:

θf-θ0=Ӭ0t+12αt2α=Ӭ0t

03

(a) the angular velocity of the wheel at the start of the3.00  s interval

The second kinetic equation in rotational motion,

θf-θ0=Ӭ0t+12αt2⇒90rad=Ӭ03.0s+122.0rads23.0s2⇒90rad=Ӭ03.0s+9rad⇒90rad-9rad=Ӭ03.0s⇒81rad=Ӭ03.0s⇒Ӭ0=27rads

Therefore, the angular velocity of the wheel at start of the 3.00sinterval is27rads

04

Calculate how long has the wheel been turning before the start of the 3.00  s interval

For angular acceleration,

α=Ӭ0t⇒t=Ӭ0α⇒t=27rads2rads2⇒t=13.5s

Therefore, the time for which the wheel has been turning before the start of the interval is13.5s

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Figure 10 - 27shows three flat disks (of the same radius) that can rotate about their centers like merry-go-rounds. Each disk consists of the same two materials, one denser than the other (density is mass per unit volume). In disks 1and 3, the denser material forms the outer half of the disk area. In disk 2, it forms the inner half of the disk area. Forces with identical magnitudes are applied tangentially to the disk, either at the outer edge or at the interface of the two materials, as shown. Rank the disks according to (a) the torque about the disk center, (b) the rotational inertia about the disk center, and (c) the angular acceleration of the disk, greatest first.

The flywheel of a steam engine runs with a constant angular velocity of . When steam is shut off, the friction of the bearings and of the air stops the wheel in 2.2 h.

(a) What is the constant angular acceleration, in revolutions per minute-squared, of the wheel during the slowdown?

(b) How many revolutions does the wheel make before stopping?

(c) At the instant the flywheel is turning at75revmin , what is the tangential component of the linear acceleration of a flywheel particle that is50 cm from the axis of rotation?

(d) What is the magnitude of the net linear acceleration of the particle in (c)?

In Fig10-61., four pulleys are connected by two belts. Pulley A (radius15 c³¾) is the drive pulley, and it rotates at.10 r²¹»å/²õPulley B (radius10 c³¾) is connected by belt 1to pulley A. Pulley B’ (radius5 c³¾) is concentric with pulley B and is rigidly attached to it. Pulley C (radius25 c³¾) is connected by belt 2to pulley B’. Calculate (a) the linear speed of a point on belt 1, (b) the angularspeed of pulley B, (c) the angular speed of pulley B’, (d) the linear speed of a point on belt2, and (e) the angular speed of pulley C. (Hint: If the belt between two pulleys does not slip, the linear speeds at the rims of the two pulleys must be equal.)

The rigid body shown in Fig.10-57consists of three particles connected by massless rods. It is to be rotated about an axis perpendicular to its plane through point P. IfM=0.40kg , a=30cm , and b=50cm, how much work is required to take the body from rest to an angular speed of 5.0 r²¹»å/²õ?

Cheetahs running at top speed have been reported at an astounding114 k³¾/³ó(about71″¾¾±/³ó) by observers driving alongside the animals. Imagine trying to measure a cheetah’s speed by keeping your vehicle abreast of the animal while also glancing at your speedometer, which is registering114 k³¾/³ó. You keep the vehicle a constantfrom the cheetah, but the noise of the vehicle causes the cheetah to continuously veer away from you along a circular path of radius92″¾. Thus, you travel along a circular path of radius.100″¾ (a) What is the angular speed of you and the cheetah around the circular paths? (b) What is the linear speed of the cheetah along its path? (If you did not account for the circular motion, you would conclude erroneously that the cheetah’s speed is114 k³¾/³ó, and that type of error was apparently made in the published reports.)
