1. The mass of each particle is, m = 0.85kg .
2. The rod length is, d = 5.6cm .
3. The mass of rod is, M = 1.2kg .
4. The angular speed of the system is, $\mathrm{Ó\neg }=0.30rad/s$.

By using the concept of moment of inertia we can calculate the moment of inertia at various points. Moment of inertia of the system is the mass times perpendicular distance square at that point. From the moment of inertia of the system we can calculate the kinetic energy of the system and is given as follows.

1. Moment of inertia at point is l = Md²
2. For a rod at one end moment of inertia is $\mathit{l}\mathbf{=}\frac{\mathbf{1}}{\mathbf{12}}\mathit{M}{\mathit{d}}^{\mathbf{2}}$
3. Kinetic energy of the system is $\mathit{K}\mathbf{=}\frac{\mathbf{1}}{\mathbf{2}}\mathit{l}{\mathit{Ó\neg }}^{\mathbf{2}}$
4. Parallel axis theorem $\mathit{l}\mathbf{=}{\mathit{l}}_{\mathbf{c}\mathbf{o}\mathbf{m}}\mathbf{+}\mathit{M}{\mathit{d}}^{\mathbf{2}}$
   Where d is the perpendicular distance.

According to parallel axis theorem moment of inertia is

For our system we have,

l₁ for first rod, l₂ for mass 1, l₃ for second rod, l₄ for mass 2.

$\begin{array}{rcl}l& =& l_1+l_2+l_3+l_4\\ l_1& =& \left(\frac{1}{12}M{d}^2+M{\left(\frac{1}{2}d\right)}^2\right)\\ l_2& =& m{d}^2\\ l_3& =& \left(\frac{1}{12}M{d}^2+M{\left(\frac{3}{2}d\right)}^2\right)\\ l_4& =& m{\left(2d\right)}^2\\ l& =& \frac{4}{12}M{d}^2+\frac{37}{12}M{d}^2+m{d}^2+4m{d}^2\left(\frac{1}{12}M{d}^2+M{\left(\frac{1}{2}d\right)}^2\right)+m{d}^2\\ & & +\left(\frac{1}{12}M{d}^2+M{\left(\frac{3}{2}d\right)}^2\right)+m{\left(2d\right)}^2\\ & =& \frac{4}{12}M{d}^2+\frac{28}{12}M{d}^2+m{d}^2+4m{d}^2\\ l& =& \frac{8}{3}M{d}^2+5m{d}^2\end{array}$

Substitute all the value in the above equation.

$\begin{array}{rcl}l& =& \frac{8}{3}×1.2kg×{\left(0.056m\right)}^2+5×0.85kg×{\left(0.056m\right)}^2\\ & =& 0.02336kg.m^2\\ & ≈& 0.023kg.m^2\end{array}$

Hence the rotational inertia is, 0.023kg.m² .

Kineticenergy of the system is

$K=\frac{1}{2}l{\mathrm{Ó\neg }}^2$

Where $\mathrm{Ó\neg }$is the angular speed of the particle.

Substitute all the value in the above equation.

role="math" localid="1661094304990" $\begin{array}{rcl}K& =& \frac{1}{2}×0.023336kg.m^2×{\left(0.30rad/s\right)}^2\\ & =& 1.05×{10}^{-3}J\\ & ≈& 1.1×{10}^{-3}J\end{array}$

Hence the kinetic energy is, $\begin{array}{rcl}& & 1.1×{10}^{-3}J\end{array}$.
