Chapter 8: Q5Q (page 201)

In Fig. 8-22, a block slides from A to C along a frictionless ramp, and then it passes through horizontal region CD, where a frictional force act on it. Is the block鈥檚 kinetic energy increasing, decreasing, or constant in (a) region AB, (b) region BC, and (c) region CD? (d) Is the block鈥檚 mechanical energy increasing, decreasing, or constant in those regions?

Short Answer

Expert verified

The block鈥檚 kinetic energy increases in the region AB
The block鈥檚 kinetic energy decreases in the region BC
The block鈥檚 kinetic energy decreases in the region CD
Mechanical energy of the block remains constant in the region AB & BC but decreases in the CD region

Step by step solution

Given information

A figure which shows the block slides from A to C along a frictionless ramp and then it passes through the horizontal region CD

To understand the concept

The problem is based on the principle of conservation of energy, which states that the total energy in an isolated system remains constant. Here this principle can be used to find whether the block鈥檚 kinetic energy increases, decrease, or remains constant in the region $AB, BC and CD$ . Also, it can be used to find whether the mechanical energy of the block is increasing, decreasing, or remains constant in $AB, BC and CD$ region.

Formula:

role="math" localid="1657184859975" ${螖贰}_{mec} = d (K . E) + dU$

(a) To find whether the block’s kinetic energy increases, decreases or remains constant in the region AB

For the conservation of energy,

${螖贰}_{mec} = d (K . E) + dU = constant$

As the height of the ramp decreases from A to B, the potential energy of the block decreases. According to the above equation, as potential energy decreases, kinetic energy increases.

Therefore, the block鈥檚 kinetic energy increases in the region AB

(b) Whether the block’s kinetic energy increases, decreases, or remains constant in the region BC

For conservation of energy

${螖贰}_{mec} = d (K . E) + dU = 0$

Velocity of the block decreases when it comes to point B, therefore its kinetic energy decreases. As the kinetic energy decreases, the potential energy increases.

Hence, the block鈥檚 kinetic energy decreases in the region BC.

(c) Whether the block’s kinetic energy increases, decreases, or remains constant in the region CD

As region CD is plane and has friction, the velocity of the block decreases when it slides through this region. Therefore, its kinetic energy decreases in the region CD

(d) Whether the mechanical energy of the block is increasing, decreasing, or remaining constant in the region AB ,BC,CD

According to this principle, when kinetic energy increases in the region AB and BC, its potential energy decreases. But, in the region CD due to friction, the kinetic energy of the block increases, and because it is a plane, the potential energy of the block remains constant.

Therefore, the mechanical energy of the block remains constant in the region AB & BC but decreases in the CD region
