1. The weight of Tarzon is,$W=68s$
2. The length of the vine is,$l=18\mathrm{m}$
3. The vertical distance covered from the top of the cliff to the bottom of the swing is,$h=3.2\mathrm{m}$
4. The maximum limit of the force in the vine is,$T=950\mathrm{N}$

Use the concept of energy conservation law and find the velocity at the lowest point. At the cliff, there is potential energy, and it is converted to kinetic energy during the swing. Use Newton’s second law and find the greatest tension in the vine. According to the law of energy conservation, energy can neither be created, nor be destroyed.

Formulae:

$$\begin{gathered} W=mg \\ U=mgh \\ K=\frac{1}{2}m{v}^2 \end{gathered}$$

where, K is kinetic energy, Uis potential energy, m is mass, v is velocity, g is an acceleration due to gravity, his height and W is work done.

The weight of Tarzan is,

$W=mg$

According to the energy conservation law, the potential energy is converted to the kinetic energy duringtheswing, and finally, the velocity at the lowest point,

$$\begin{gathered} mgh=\frac{1}{2}m{v}^2 \\ gh=\frac{1}{2}{v}^2 \\ {v}^2=2gh \end{gathered}$$

Examine the tension in the string at the lowest point. If it isn’t breaking, then it has greatest tension.

The free body diagram is shown at the lowest point. The centripetal force and tension are acting in upward direction and weight in downward direction. Use the sign convention according to the motion of the body. According to Newton’s second law,

$T-mg=\frac{m{v}^2}{r}$

Here,

$$\begin{gathered} r=l \\ =18m \\ T=\frac{{\mathrm{mv}}^2}{\mathrm{l}}+\mathrm{mg} \\ T=m\left(\frac{v^2}{l}+g\right) \\ T=\mathrm{m}\left(\frac{2gh}{l}+g\right) \\ T=\mathrm{mg}\left(\frac{2h}{l}+1\right) \\ T=688\mathrm{N}\left(\frac{2×3.2\mathrm{m}}{18\mathrm{m}}+1\right) \\ T=933\mathrm{N} \end{gathered}$$

Therefore, no, the vine does not break. The maximum limit of the force in the vine is $T=950\mathrm{N}$ but here the maximum tension in the vine at the lowest pointis $T=933\mathrm{N}$. It is less than the maximum limit.

The maximum force in the vine at the lowest point is,

$T=933\mathrm{N}$

Hence,the greatest force acting on the vine is,$T=933\mathrm{N}$

Therefore, the maximum tension in the vine at the lowest point can be found by using Newton’s second law and energy conservation law.
