A particle with a mass of1.00×10-20kgis oscillating with simple harmonic motion with a period of 1.00×10-5sand a maximum speed of1.00×103m/s.

  1. Calculate the angular frequency of the particle.
  2. Calculate the maximum displacement of the particle.

Short Answer

Expert verified
  1. The angular frequency of the particle is 6.28×105rad/sec.
  2. The maximum displacement of the particle is 1.59×10-3m.

Step by step solution

01

Stating the given data

  1. Mass of particle,m=1×10-20kg
  2. Time period of SHM,data-custom-editor="chemistry" t=1×10-5sec
  3. Maximum speed of the body,v=1×103m/s
02

Understanding the concept of motion

We can find the angular frequency by using the time period of motion. And maximum displacement can be found by using the formulae of maximum velocity and angular frequency.

Formula:

Angular frequency of a body in oscillation

Ó¬=2Ï€T (i)

The velocity of a body undergoing simple harmonic motion

v=Ó¬Xm (ii)

03

a) Calculation of angular frequency of the body

Using equation (i) and the given values, the angular frequency is given as follows:

Ӭ=2π1×10-5=6.28×105rad/sec

Hence, the angular frequency is 6.28×105rad/sec.

04

b) Calculation of maximum displacement

Using the given values and equation (ii), we get the maximum displacement as follows:

1×103=6.28×105×XmXm=1.59×10-3m

Hence, the maximum displacement is 1.59×10-3m.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Question: A0.12 kgbody undergoes simple harmonic motion of amplitude 8.5 cmand period20 s.

  1. What is the magnitude of the maximum force acting on it?
  2. If the oscillations are produced by a spring, what is the spring constant?

Question: A thin uniform rod (mass m =0.50 kg) swings about an axis that passes through one end of the rod and is perpendicular to the plane of the swing. The rod swings with a period of1.5 sand an angular amplitude of 100.

  1. What is the length of the rod?
  2. What is the maximum kinetic energy of the rod as it swings?

In Figure, a 2.50 kgdisk of diameter D=42.0 cmis supported by a rod of length L=76.0 cmand negligible mass that is pivoted at its end.

  1. With the massless torsion spring unconnected, what is the period of oscillation?
  2. With the torsion spring connected, the rod is vertical at equilibrium. What is the torsion constant of the spring if the period of oscillation has been decreased by 0.500s?

A pendulum is formed by pivoting a long thin rod about a point on the rod. In a series of experiments, the period is measured as a function of the distance xbetween the pivot point and the rod’s center.

  1. If the rod’s length is L=2.20 mand its mass is m=22.1 g, what is the minimum period?
  2. If xis chosen to minimize the period and then Lis increased, does the period increase, decrease, or remain the same?
  3. If, instead, m is increased without Lincreasing, does the period increase, decrease, or remain the same?

In Figure, a block weighing 14.0 N, which can slide without friction on

an incline at angle40.0∘, is connected to the top of the incline by a massless

spring of unstretched length 0.450 mand spring constant 120 N/m.

a) How far from the top of the incline is the block’s equilibrium point?

b) If the block is pulled slightly down the incline and released, what is the period

of the resulting oscillations?
