• Windows 1, 2 and 3: regularly spaced vertically.
• Windows 4, 5 and 6: irregularly spaced horizontally.

This problem is based on the concept of projectile motion. When a particle is thrown near the earth’s surface, it travels along a curved path under constant acceleration directed towards the center of the earth surface. Also, it deals with the kinematic equations of motion in which the motion can be described with constant acceleration. This problem can be solved by using the kinematic equations for two-dimensional motion:

horizontal motion with constant speed and vertical motion with acceleration due to gravity.

Formulae:

$$\begin{gathered} v_{fy}=y_{0y}-gt \\ ∆y=v_{0y}t-\left(\frac{1}{2}g{t}^2\right) \end{gathered}$$

Since the acceleration is in the downward direction, velocity would decrease with height and hence time would increase,

Rank : 3 > 2 > 1

$v_{fy}=v_{0y}-gt$

As time increases, average speed decreases.

Hence,

Rank : 1 > 2 > 3

To pass horizontally, time required will be same for each window because there is no acceleration due to horizontal motion.

Hence,

Rank : 1 = 2 = 3

During the movement in the direction of an acceleration speed is increasing with time.

Hence,

Rank : 6 > 5 > 4
