The position of an object moving along an x axis is given by,x=3t-4t2+t3 where x is in metres and tin seconds. Find the position of the object at following values of t:a) 1sec,(b)2sec, (c) 3sec, and (d) 4sec,(e) What is the object’s displacement between t=0and t=4sec? (f)What is its average velocity for the time interval from t=2sto t=4s? (g)Graph x vs t for0≤t≤4secand indicate how the answer for f can be found on the graph.

Short Answer

Expert verified
  1. The position of the object at t=1s is X=0m.
  2. The position of the object at t=2s is X=-2.
  3. The position of the object at t=3s is X=0.
  4. The position of the object at t=4s is X=12.
  5. The displacement of the object is +12m.
  6. Average velocity of the object is +7m/s.

Step by step solution

01

Given data

The position of the object,xt=3t-4t2+t3

02

Understanding the displacement and average velocity

Displacement of a particle gives the change in position of the particle. Average velocity is the ratio between the total displacement to the total time interval.

The expression for the displacement is as follows:

Δx=x2-x1 (i)

Here, X1is the initial position, and is X2the final position.

The expression for the average velocity is as follows:

vavg=ΔxΔt (ii)

Here, ΔXis the displacement, and Δtis the time interval.

03

(a) Determination of the position at t = 1 s

The position of the object is given as follows:

xt=3t-4t2+t3

The position of the object at t=1 s is calculated as follows:

x1=31-412+13=4-4=0m

Thus, the position of the object at t=1 s is 0 m.

04

(b) Determination of the position at t = 2 s

The position of the object at t=2 s is calculated as follows:

x2=32-422+23=14-16=-2m

Thus, the position of the object at t=2s is -2m.

05

(c) Determination of the position at t = 3 s

The position of the object at t=3 s is calculated as follows:

x3=33-432+33=36-36=0m

Thus, the position of the object at t=3 s is 0m.

06

(d) Determination of the position at t = 4 s

The position of the object at t=4s is calculated as follows:

x4=34-442+43=76-64=12m

Thus, the position of the object at t=4 s is 12m.

07

(e) Determination of the displacements between the given time interval

The position of the object at t=0 s is calculated as follows:

x0=30-402+03=0m

The displacement of the object between t=0s and t=4 s is calculated as follows:

Δx=x4-x0=12-0=+12m

Thus, the displacement of the object is +12 m.

08

(f) Determination of the average velocity between the given time interval

The displacement of the object between t=2 s and t=4 s is calculated as follows:

Δx=x4-x2=12--2=+14m

The average velocity of the object is calculated as follows:

vavg=ΔxΔt=+14m4s-2s=+7m/s

09

(g) Plot the x-t graph and determination of the average velocity from it

Below is the graph of position vs. time for0≤t≤4sec . To find the average velocity between t=2 sec to t=4 sec , you can connect the points on the graph as shown by the black line in the graph. The slope of this black line will be the average velocity.
